Scilab [trunk]: scilab/modules/graphics/src/c/Plo2dEch.c File Reference

static void show_scales __PARAMS ( (ScaleList *listptr) ) [static]

static void DeleteWCScale __PARAMS ( (WCScaleList *l) ) [static]

static int get_scale_win __PARAMS ( (ScaleList *listptr, integer wi, double *subwin) ) [static]

static void set_window_scale __PARAMS ( (integer i, WCScaleList *scale) ) [static]

static int same_subwin __PARAMS ( (double lsubwin_rect[4], double subwin_rect[4]) ) [static]

static WCScaleList* check_subwin_wcscale __PARAMS ( (WCScaleList *listptr, double *) ) [static]

static WCScaleList* new_wcscale __PARAMS ( (WCScaleList *val) ) [static]

static void set_scale_win __PARAMS ( (ScaleList **listptr, integer i, WCScaleList *s) ) [static]

static integer curwin __PARAMS ( (void) ) [static]

static void scale_copy __PARAMS ( (WCScaleList *s1, WCScaleList *s2) ) [static]

void C2F() axis2d	(	double *	alpha,
		double *	initpoint,
		double *	size,
		integer *	initpoint1,
		double *	size1
	)

meme chose mais pour axis

Definition at line 1014 of file Plo2dEch.c.

References Abs, Cscale, M_PI, wcscalelist::Wscx1, wcscalelist::Wscy1, XScale(), and YScale().

Referenced by drawaxis_1().

01019 {
01020   double sina ,cosa;
01021   double xx,yy,scl;
01022   /* pour eviter des problemes numerique quand Cscale.scx1 ou Cscale.scy1 sont
01023    *  tres petits et cosal ou sinal aussi
01024    */
01025   if ( Abs(*alpha) == 90 )
01026     {
01027       scl=Cscale.Wscy1;
01028     }
01029   else
01030     {
01031       if (Abs(*alpha) == 0)
01032         {
01033           scl=Cscale.Wscx1;
01034         }
01035       else
01036         {
01037           sina= sin(*alpha * M_PI/180.0);
01038           cosa= cos(*alpha * M_PI/180.0);
01039           xx= cosa*Cscale.Wscx1; xx *= xx;
01040           yy= sina*Cscale.Wscy1; yy *= yy;
01041           scl= sqrt(xx+yy);
01042         }
01043     }
01044   size1[0] = size[0]*scl;
01045   size1[1]=  size[1]*scl;
01046   size1[2]=  size[2];
01047   initpoint1[0]= XScale(initpoint[0]);
01048   initpoint1[1]= YScale(initpoint[1]);
01049 }

Here is the call graph for this function:

Here is the caller graph for this function:

static WCScaleList* check_subwin_wcscale	(	WCScaleList *	listptr,
		subwin_rect
	)			`[static]`

Definition at line 251 of file Plo2dEch.c.

References NULL, and same_subwin().

Referenced by get_scale_win(), and set_scale_win().

00254 {
00255   if ( listptr == (WCScaleList  *) NULL)  return NULL;
00256   if ( same_subwin( listptr->subwin_rect,subwin_rect))
00257     return listptr;
00258   else
00259     return check_subwin_wcscale(listptr->next,subwin_rect);
00260 }

Here is the call graph for this function:

Here is the caller graph for this function:

void Cscale2default ( void )

Definition at line 105 of file Plo2dEch.c.

References Cscale, curwin(), Defscale, scale_copy(), and set_window_scale().

Referenced by CleanPlots(), InitMissileXgc(), and initsubwin().

00106 {
00107   scale_copy(&Cscale,&Defscale);  set_window_scale(curwin(),&Cscale);
00108 }

Here is the call graph for this function:

Here is the caller graph for this function:

static integer curwin ( void ) [static]

Definition at line 367 of file Plo2dEch.c.

References C2F, dr(), L, PD0, and PI0.

Referenced by Cscale2default(), DeleteSGWin(), and Nsetscale2d().

00368 {
00369   integer verbose=0,narg,winnum;
00370   C2F(dr)("xget","window",&verbose,&winnum,&narg ,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
00371   return(winnum);
00372 }

Here is the call graph for this function:

Here is the caller graph for this function:

void del_window_scale ( integer i )

Definition at line 281 of file Plo2dEch.c.

References DeleteWCScale(), FREE, scalelist::next, NULL, scalelist::scales, The_List, and scalelist::Win.

Referenced by CleanPlots(), and DeleteSGWin().

00282 {
00283   ScaleList *loc, *loc1;
00284   /* check head of The_List */
00285   if ( The_List == NULL) return ;
00286   if ( The_List->Win == i)
00287     {
00288       loc1= The_List ;
00289       The_List = The_List->next;
00290       DeleteWCScale(loc1->scales);
00291       FREE(loc1);
00292       return;
00293     }
00294   loc1= The_List;
00295   loc = The_List->next;
00296   while ( loc != NULL)
00297     {
00298       if ( loc->Win == i )
00299         {
00300           loc1->next = loc->next;
00301           DeleteWCScale(loc->scales);
00302           FREE(loc);
00303           return ;
00304         }
00305       else
00306         {
00307           loc1 = loc;
00308           loc  = loc->next;
00309         }
00310     }
00311 }

Here is the call graph for this function:

Here is the caller graph for this function:

static void DeleteWCScale ( WCScaleList * l ) [static]

Definition at line 313 of file Plo2dEch.c.

References FREE, and NULL.

Referenced by del_window_scale().

00315 {
00316   if ( l != NULL)
00317     {
00318       DeleteWCScale(l->next);
00319       FREE(l);
00320     }
00321 }

Here is the caller graph for this function:

int EchCheckSCPlots ( )

Changement interactif d'echelle

int C2F() echelle2d	(	double	x[],
		double	y[],
		integer	x1[],
		integer	yy1[],
		integer *	n1,
		integer *	n2,
		char	dir[],
		integer	lstr
	)

Definition at line 860 of file Plo2dEch.c.

References C2F, n, xechelle2d(), and yechelle2d().

Referenced by boundingbox_1(), displaynumbers_1(), drawarrows_1(), drawGrayplotEntity(), drawpolyline_1(), drawPolylineEntity(), drawpolylines_1(), drawpolymark_1(), drawsegments_1(), fillpolyline_1(), fillpolylines_1(), I3dRotation(), Objstring(), sci_xchange(), xclick_1(), xclick_2(), xclick_any_1(), xgetmouse2(), xgetmouse_1(), and xset_1().

00869 {
00870   int n=(*n1)*(*n2);
00871   C2F(xechelle2d)(x,x1,&n,dir,lstr);
00872   C2F(yechelle2d)(y,yy1,&n,dir,lstr);
00873   return(0);
00874 }

Here is the call graph for this function:

Here is the caller graph for this function:

void C2F() echelle2dl	(	double	x[],
		double	y[],
		integer	x1[],
		integer	yy1[],
		integer *	n1,
		integer *	n2,
		char *	dir
	)

Definition at line 884 of file Plo2dEch.c.

References Cscale, i, inint, sciprint(), wcscalelist::Wscx1, and wcscalelist::Wscy1.

Referenced by boundingbox_1(), cleararea_1(), computeRealArrowSize(), drawarc_1(), drawarrows_1(), fillarc_1(), fillrectangle_1(), Objstring(), xset_1(), and xstringb_1().

00891 {
00892   integer i;
00893   if (strcmp("f2i",dir)==0)
00894     {
00895       for ( i=0 ; i < (*n1)*(*n2) ; i++)
00896         {
00897           x1[i]=inint( Cscale.Wscx1*( x[i]));
00898           yy1[i]=inint( Cscale.Wscy1*( y[i]));
00899         }
00900     }
00901   else if (strcmp("i2f",dir)==0)
00902     {
00903       for ( i=0 ; i < (*n1)*(*n2) ; i++)
00904         {
00905           x[i]=x1[i]/Cscale.Wscx1;
00906           y[i]=yy1[i]/Cscale.Wscy1;
00907         }
00908     }
00909   else
00910     sciprint(" Wrong dir %s argument in echelle2d\r\n",dir);
00911 }

Here is the call graph for this function:

Here is the caller graph for this function:

void C2F() ellipse2d	(	double	x[],
		integer	x1[],
		integer *	n,
		char *	dir
	)

meme chose mais pour transformer des ellipses

double to integer (pixel) direction

Definition at line 915 of file Plo2dEch.c.

References Cscale, i, inint, sciprint(), wcscalelist::Wscx1, wcscalelist::Wscy1, XPi2R(), XScale(), YPi2R(), and YScale().

Referenced by drawarcs_1(), and fillarcs_1().

00916 {
00917   integer i;
00918   if (strcmp("f2i",dir)==0)
00919     {
00921       for ( i=0 ; i < (*n) ; i=i+6)
00922         {
00923           x1[i  ]= XScale(x[i]);
00924           x1[i+1]= YScale(x[i+1]);
00925           x1[i+2]= inint( Cscale.Wscx1*( x[i+2]));
00926           x1[i+3]= inint( Cscale.Wscy1*( x[i+3]));
00927           x1[i+4]= inint( x[i+4]);
00928           x1[i+5]= inint( x[i+5]);
00929         }
00930     }
00931   else if (strcmp("i2f",dir)==0)
00932     {
00933       for ( i=0 ; i < (*n) ; i=i+6)
00934         {
00935           x[i]=   XPi2R(x1[i]);
00936           x[i+1]= YPi2R( x1[i+1] );
00937           x[i+2]= x1[i+2]/Cscale.Wscx1;
00938           x[i+3]= x1[i+3]/Cscale.Wscy1;
00939           x[i+4]= x1[i+4];
00940           x[i+5]= x1[i+5];
00941         }
00942     }
00943   else
00944     sciprint(" Wrong dir %s argument in echelle2d\r\n",dir);
00945 }

Here is the call graph for this function:

Here is the caller graph for this function:

void get_cwindow_dims ( int wdims[2] )

Definition at line 785 of file Plo2dEch.c.

References C2F, dr(), L, PD0, and PI0.

00786 {
00787   int verbose=0,narg;
00788   C2F(dr)("xget","wdim",&verbose,wdims,&narg, PI0, PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
00789 }

Here is the call graph for this function:

void get_frame_in_pixel ( integer WIRect[] )

Definition at line 596 of file Plo2dEch.c.

References Cscale, and wcscalelist::WIRect1.

00597 {
00598   /* ajout bruno */
00599   WIRect[0] = Cscale.WIRect1[0];
00600   WIRect[1] = Cscale.WIRect1[1];
00601   WIRect[2] = Cscale.WIRect1[0] +  Cscale.WIRect1[2];
00602   WIRect[3] = Cscale.WIRect1[1] +  Cscale.WIRect1[3];
00603 }

void get_margin_in_pixel ( integer Margin[] )

Definition at line 605 of file Plo2dEch.c.

References wcscalelist::axis, Cscale, and wcscalelist::WIRect1.

00606 {
00607   /* added by bruno
00608    *       Margin[0]: left margin
00609    *       Margin[1]: right margin
00610    *       Margin[2]: up margin
00611    *       Margin[3]: down margin
00612    */
00613   double coef_w = 1.0 - Cscale.axis[0] - Cscale.axis[1];
00614   double coef_h = 1.0 - Cscale.axis[2] - Cscale.axis[3];
00615   Margin[0] = (integer) ( Cscale.axis[0]/coef_w * (double) Cscale.WIRect1[2]);
00616   Margin[1] = (integer) ( Cscale.axis[1]/coef_w * (double) Cscale.WIRect1[2]);
00617   Margin[2] = (integer) ( Cscale.axis[2]/coef_h * (double) Cscale.WIRect1[3]);
00618   Margin[3] = (integer) ( Cscale.axis[3]/coef_h * (double) Cscale.WIRect1[3]);
00619 }

static int get_scale_win	(	ScaleList *	listptr,
		integer	wi,
		double *	subwin
	)			`[static]`

Definition at line 128 of file Plo2dEch.c.

References check_subwin_wcscale(), Cscale, NULL, and scale_copy().

Referenced by get_window_scale().

00132 {
00133   if (listptr != (ScaleList  *) NULL)
00134     {
00135       if ((listptr->Win) == wi)
00136         {
00137           if ( subwin == NULL)
00138             {
00139               scale_copy(&Cscale,listptr->scales);
00140               return 1;
00141             }
00142           else
00143             {
00144               WCScaleList *loc = check_subwin_wcscale(listptr->scales,subwin);
00145               if ( loc != NULL)
00146                 {
00147                   scale_copy(&Cscale,loc);
00148                   return 1;
00149                 }
00150               else
00151                 {
00152                   return 0;
00153                 }
00154             }
00155         }
00156       else
00157         return get_scale_win(listptr->next,wi,subwin);
00158     }
00159   return 0;
00160 }

Here is the call graph for this function:

Here is the caller graph for this function:

int get_window_scale	(	integer	i,
		double *	subwin
	)

Definition at line 123 of file Plo2dEch.c.

References get_scale_win(), L, Max, and The_List.

Referenced by DeleteSGWin(), Nsetscale2d(), and SwitchWindow().

00124 {
00125   return get_scale_win(The_List,Max(0L,i),subwin);
00126 }

Here is the call graph for this function:

Here is the caller graph for this function:

void getPixelCoordinates	(	sciPointObj *	pSubWin,
		double	coord3d[3],
		int	pixCoord[2]
	)

convert the coordinates of a 2d or 3d point to its pixel coordinates.

Parameters:

	pSubWin	SubWindow in which the point is, might be either in 2d or 3d.
	coord3d	Coordinates of the point in the axes. If the subwin is in 2d, only the first two coordinates are used.

Definition at line 1846 of file Plo2dEch.c.

References pSUBWIN_FEATURE, ReverseDataFor3D(), trans3d(), XDouble2Pixel, and YDouble2Pixel.

Referenced by drawTextEntity(), and getTextBoundingBox().

01847 {
01848
01849   if ( pSUBWIN_FEATURE (pSubWin)->is3d )
01850   {
01851     int n = 1 ;
01852
01853     double xvect = coord3d[0] ;
01854     double yvect = coord3d[1] ;
01855     double zvect = coord3d[2] ;
01856
01857     ReverseDataFor3D(pSubWin,&xvect,&yvect,&zvect,n);
01858     trans3d(pSubWin,n,&(pixCoord[0]),&(pixCoord[1]),&xvect,&yvect,&zvect ) ;
01859   }
01860   else
01861   {
01862     pixCoord[0] = XDouble2Pixel( coord3d[0] ) ;
01863     pixCoord[1] = YDouble2Pixel( coord3d[1] ) ;
01864   }
01865 }

Here is the call graph for this function:

Here is the caller graph for this function:

int getscale2d	(	double	WRect[4],
		double	FRect[4],
		char *	logscale,
		double	ARect[4]
	)

Definition at line 571 of file Plo2dEch.c.

References wcscalelist::axis, Cscale, wcscalelist::frect, i, wcscalelist::logflag, and wcscalelist::subwin_rect.

Referenced by sci_xgetech(), SetEch3d1(), and updateScale3d().

00572 {
00573   integer i;
00574   static double ten=10.0;
00575   logscale[0] = Cscale.logflag[0];
00576   logscale[1] = Cscale.logflag[1];
00577   for ( i=0; i < 4 ; i++)
00578     {
00579       WRect[i]=Cscale.subwin_rect[i];
00580       FRect[i]=Cscale.frect[i];
00581       ARect[i]=Cscale.axis[i];
00582     }
00583   if (logscale[0]=='l')
00584     {
00585       FRect[0]=pow(ten,FRect[0]);
00586       FRect[2]=pow(ten,FRect[2]);
00587     }
00588   if (logscale[1]=='l')
00589     {
00590       FRect[1]=pow(ten,FRect[1]);
00591       FRect[3]=pow(ten,FRect[3]);
00592     }
00593   return(0);
00594 }

Here is the caller graph for this function:

void Gr_Rescale	(	char *	logFlags,
		double *	FRectI,
		integer *	Xdec,
		integer *	Ydec,
		integer *	xnax,
		integer *	ynax
	)

Definition at line 1470 of file Plo2dEch.c.

References C2F, graduate(), i, inint, pSUBWIN_FEATURE, and sciGetCurrentSubWin().

01471 {
01472   double FRectO[4];
01473   sciPointObj *psubwin;
01474   int i;
01475
01477     psubwin = sciGetCurrentSubWin();
01478     for (i=0;i<4 ; i++)
01479       pSUBWIN_FEATURE (psubwin)->axes.limits[i+1]=FRectI[i];
01480
01481
01482   if (logFlags[0] == 'n')
01483     {
01484       if (!pSUBWIN_FEATURE (psubwin)->tight_limits )
01485         {
01486           C2F(graduate)(FRectI,FRectI+2,FRectO,FRectO+2,xnax,xnax+1,Xdec,Xdec+1,Xdec+2);
01487           FRectI[0]=FRectO[0];FRectI[2]=FRectO[2];
01488         }
01489
01490       else
01491         {
01492           C2F(graduate)(FRectI,FRectI+2,FRectO,FRectO+2,xnax,xnax+1,Xdec,Xdec+1,Xdec+2);
01493         }
01494     }
01495   else
01496     {
01497       Xdec[0]=inint(FRectI[0]);
01498       Xdec[1]=inint(FRectI[2]);
01499       Xdec[2]=0;
01500     }
01501   if (logFlags[1] == 'n')
01502     {
01503       if ( !pSUBWIN_FEATURE (psubwin)->tight_limits)
01504         {
01505           C2F(graduate)(FRectI+1,FRectI+3,FRectO+1,FRectO+3,ynax,ynax+1,Ydec,Ydec+1,Ydec+2);
01506           FRectI[1]=FRectO[1];FRectI[3]=FRectO[3];
01507         }
01508       else
01509         {
01510           C2F(graduate)(FRectI+1,FRectI+3,FRectO+1,FRectO+3,ynax,ynax+1,Ydec,Ydec+1,Ydec+2);
01511         }
01512     }
01513   else
01514     {
01515       Ydec[0]=inint(FRectI[1]);Ydec[1]=inint(FRectI[3]);Ydec[2]=0;
01516     }
01517
01518
01519 }

Here is the call graph for this function:

static WCScaleList* new_wcscale ( WCScaleList * val ) [static]

Definition at line 239 of file Plo2dEch.c.

References MALLOC, NULL, and scale_copy().

Referenced by set_scale_win().

00241 {
00242   WCScaleList *new ;
00243   if ((new = (WCScaleList *) MALLOC( sizeof (WCScaleList))) == NULL)
00244     return NULL;
00245   new->next = (WCScaleList *) 0;
00246   new->prev = (WCScaleList *) 0;
00247   scale_copy(new,val);
00248   return new;
00249 }

Here is the call graph for this function:

Here is the caller graph for this function:

int C2F() Nsetscale2d	(	double	WRect[4],
		double	ARect[4],
		double	FRect[4],
		char *	logscale,
		integer	l1
	)

Definition at line 464 of file Plo2dEch.c.

References wcscalelist::axis, ConstructSubWin(), Cscale, curwin(), wcscalelist::flag, wcscalelist::frect, get_window_scale(), wcscalelist::logflag, NULL, pSUBWIN_FEATURE, same_subwin(), sciGetCurrentFigure(), sciGetCurrentSubWin(), sciIsExistingSubWin(), sciprint(), sciSetCurrentObj(), sciSetSelectedSubWin(), set_scale(), set_window_scale(), and wcscalelist::subwin_rect.

Referenced by sci_xsetech().

00469 {
00470   /* if some arguments are null pointer we set them to
00471    * the corresponding Cscale value.
00472    * this is only important for StoreNEch which do not work with null arguments
00473    */
00474   /* char flag[] = "tfffff";*/ /* flag to specify which arguments have changed*/
00475   /* 14/03/2002*/
00476   sciPointObj *masousfen;
00477
00478   char flag[7];
00479   strcpy(flag,"tfffff");
00480
00482   if ( WRect != NULL)
00483     {
00484       /* Ajout djalel */
00485
00486       if (( masousfen = sciIsExistingSubWin (WRect)) != (sciPointObj *)NULL)
00487         sciSetSelectedSubWin(masousfen);
00488       else if ((masousfen = ConstructSubWin (sciGetCurrentFigure(), 0)) != NULL)
00489       {
00490         /* F.Leray Adding here 26.03.04*/
00491         sciSetCurrentObj(masousfen);
00492         sciSetSelectedSubWin(masousfen);
00493         pSUBWIN_FEATURE (masousfen)->WRect[0]   = WRect[0];
00494         pSUBWIN_FEATURE (masousfen)->WRect[1]   = WRect[1];
00495         pSUBWIN_FEATURE (masousfen)->WRect[2]   = WRect[2];
00496         pSUBWIN_FEATURE (masousfen)->WRect[3]   = WRect[3];
00497       }
00498
00499       /* a subwindow is specified */
00500       flag[1]='t';
00501       if (! same_subwin( WRect, Cscale.subwin_rect))
00502         {
00503           /* we are using a new subwin we keep current state
00504            * in scale list
00505            */
00506           set_window_scale(curwin(),&Cscale);
00507           /* now we try to extract a previous scale with WRect as subwin
00508            * which becomes the new Cscale if it is found
00509            */
00510           if ( get_window_scale(curwin(),WRect) == 0 )
00511             {
00512               /* this is the first time WRect is used : we reset Cscale flag
00513                * Note also that if FRect is also specified in this call
00514                * Cscale.flag will be set to 1 bellow
00515                */
00516               Cscale.flag = 0;
00517             }
00518         }
00519     }
00520   else WRect = Cscale.subwin_rect;
00521   if (FRect != NULL)
00522   {
00523     masousfen=sciGetCurrentSubWin();
00524     pSUBWIN_FEATURE (masousfen)->SRect[0]   = FRect[0];
00525     pSUBWIN_FEATURE (masousfen)->SRect[2]   = FRect[1];
00526     pSUBWIN_FEATURE (masousfen)->SRect[1]   = FRect[2];
00527     pSUBWIN_FEATURE (masousfen)->SRect[3]   = FRect[3];
00528   }
00529   if ( FRect != NULL) flag[2]='t'; else FRect = Cscale.frect;
00530
00531
00532   if (ARect != NULL)
00533   {
00534     masousfen=sciGetCurrentSubWin();
00535     pSUBWIN_FEATURE (masousfen)->ARect[0]   = ARect[0];
00536     pSUBWIN_FEATURE (masousfen)->ARect[1]   = ARect[1];
00537     pSUBWIN_FEATURE (masousfen)->ARect[2]   = ARect[2];
00538     pSUBWIN_FEATURE (masousfen)->ARect[3]   = ARect[3];
00539   }
00540
00541   if ( ARect != NULL) flag[5]='t'; else ARect = Cscale.axis;
00542   if ( logscale != NULL) flag[4] ='t'; else logscale = Cscale.logflag;
00543   if ( flag[4] == 't' && flag[2] == 't' )
00544     {
00545       if (logscale[0]=='l')
00546         {
00547           if ( FRect[0] <= 0 || FRect[2] <= 0 )
00548             {
00549               sciprint("Warning: negative boundaries on x scale with a log scale \n");
00550               FRect[0]=1.e-8;FRect[2]=1.e+8;
00551             }
00552           FRect[0]=log10(FRect[0]);
00553           FRect[2]=log10(FRect[2]);
00554         }
00555       if (logscale[1]=='l')
00556         {
00557           if ( FRect[1] <= 0 || FRect[3] <= 0 )
00558             {
00559               sciprint("Warning: negative boundaries on y scale with a log scale \n");
00560               FRect[1]=1.e-8;FRect[3]=1.e+8;
00561             }
00562           FRect[1]=log10(FRect[1]);
00563           FRect[3]=log10(FRect[3]);
00564         }
00565     }
00566   set_scale(flag,WRect,FRect,NULL,logscale,ARect);
00567   return(0);
00568 }

Here is the call graph for this function:

Here is the caller graph for this function:

int PixelHeight2d	(	sciPointObj *	parentSubWin,
		double	posY,
		double	height
	)

Convert a length from user coord. to pixels in 2D. This function is similar to HDouble2Pixel, but also use the logmode in 3D.

Parameters:

	parentSubWin	Axes in which the length is computed.
	posY	Y coordinate of where the distance is transformed (only used in log mode).
	height	converted height in user coord.

Returns:: the corresponding length in pixels.

Definition at line 1867 of file Plo2dEch.c.

References HLogScale, HScale, and pSUBWIN_FEATURE.

Referenced by drawTextEntity(), and getTextBoundingBox().

01868 {
01869   if ( pSUBWIN_FEATURE( parentSubWin )->logflags[1] == 'l' )
01870   {
01871     return HLogScale( posY, height ) ;
01872   }
01873
01874   return HScale( height ) ;
01875
01876 }

Here is the caller graph for this function:

int PixelWidth2d	(	sciPointObj *	parentSubWin,
		double	posX,
		double	width
	)

Convert a length from user coord. to pixels in 2D. This function is similar to WDouble2Pixel, but also use the logmode in 3D.

Parameters:

	parentSubWin	Axes in which the length is computed.
	posX	X coordinate of where the distance is transformed (only used in log mode).
	height	converted width in user coord.

Returns:: the corresponding length in pixels.

Definition at line 1878 of file Plo2dEch.c.

References pSUBWIN_FEATURE, WLogScale, and WScale.

Referenced by drawTextEntity(), and getTextBoundingBox().

01879 {
01880   if ( pSUBWIN_FEATURE( parentSubWin )->logflags[0] == 'l' )
01881   {
01882     return WLogScale( posX, width ) ;
01883   }
01884
01885   return WScale( width ) ;
01886
01887 }

Here is the caller graph for this function:

void Plo2d2RealToPixel	(	integer *	n1,
		integer *	n2,
		double *	x,
		double *	y,
		integer *	xm,
		integer *	ym,
		char *	xf
	)

Definition at line 1958 of file Plo2dEch.c.

References i, j, XLogScale(), XScale(), YLogScale(), and YScale().

Referenced by drawPolylineEntity().

01959 {
01960   integer i,j;
01962   if ((int)strlen(xf) >= 3 && xf[2]=='l')
01963   {
01964     for ( i=0 ; i < (*n2) ; i++)
01965       for (j=0 ; j< (*n1) ; j++)
01966         ym[2*i+1+2*(*n2)*j]= ym[2*i+2*(*n2)*j]= YLogScale(y[i+(*n2)*j]);
01967   }
01968   else
01969   {
01970     for ( i=0 ; i < (*n2) ; i++)
01971       for (j=0 ; j< (*n1) ; j++)
01972         ym[2*i+1+2*(*n2)*j]= ym[2*i+2*(*n2)*j]= YScale(y[i+(*n2)*j]);
01973   }
01974
01976   switch (xf[0])
01977   {
01978   case 'e' :
01980     if ((int)strlen(xf) >= 2 && xf[1]=='l')
01981       for (j=0 ; j< (*n1) ; j++)
01982       {
01983         for ( i=1 ; i < (*n2) ; i++)
01984         {
01985           xm[2*i+2*(*n2)*j]= XLogScale(i+1.0);
01986           xm[2*i-1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
01987
01988         }
01989         xm[2*(*n2)*j]= XScale(0);
01990         xm[2*(*n2)-1+ 2*(*n2)*j]= xm[2*(*n2-1)+ 2*(*n2)*j];
01991       }
01992     else
01993       for (j=0 ; j< (*n1) ; j++)
01994       {
01995         for ( i=1 ; i < (*n2) ; i++)
01996         {
01997           xm[2*i+2*(*n2)*j]= XScale((i+1.0));
01998           xm[2*i-1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
01999
02000         }
02001         xm[2*(*n2)*j]= XScale(1.0);
02002         xm[2*(*n2)-1+ 2*(*n2)*j]=        xm[2*(*n2-1)+ 2*(*n2)*j];
02003       }
02004       break ;
02005   case 'o' :
02006     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02007       for (j=0 ; j< (*n1) ; j++)
02008       {
02009         for ( i=1 ; i < (*n2) ; i++)
02010         {
02011
02012           xm[2*i+2*(*n2)*j]= XLogScale(x[i]);
02013           xm[2*i-1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02014         }
02015         xm[2*(*n2)*j]= XLogScale(x[0]);
02016         xm[2*(*n2)-1+ 2*(*n2)*j]= xm[2*(*n2-1)+ 2*(*n2)*j];
02017       }
02018     else
02019       for (j=0 ; j< (*n1) ; j++)
02020       {
02021         for ( i=1 ; i < (*n2) ; i++)
02022         {
02023           xm[2*i+2*(*n2)*j]= XScale(x[i]);
02024           xm[2*i-1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02025
02026         }
02027         xm[2*(*n2)*j]= XScale(x[0]);
02028         xm[2*(*n2)-1+ 2*(*n2)*j]= xm[2*(*n2-1)+ 2*(*n2)*j];
02029       }
02030       break;
02031   case 'g' :
02032   default:
02033     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02034       for (j=0 ; j< (*n1) ; j++)
02035       {
02036         for ( i=1 ; i < (*n2) ; i++)
02037         {
02038           xm[2*i+2*(*n2)*j]= XLogScale(x[i+(*n2)*j]);
02039           xm[2*i-1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02040
02041         }
02042         xm[2*(*n2)*j]= XLogScale(x[(*n2)*j]);
02043         xm[2*(*n2)-1+ 2*(*n2)*j]= xm[2*(*n2-1)+ 2*(*n2)*j];
02044       }
02045     else
02046       for (j=0 ; j< (*n1) ; j++)
02047       {
02048         for ( i=1 ; i < (*n2) ; i++)
02049         {
02050           xm[2*i+2*(*n2)*j]= XScale(x[i+(*n2)*j]);
02051           xm[2*i-1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02052
02053         }
02054         xm[2*(*n2)*j]= XScale(x[(*n2)*j]);
02055         xm[2*(*n2)-1+ 2*(*n2)*j]= xm[2*(*n2-1)+ 2*(*n2)*j];
02056       }
02057       break;
02058   }
02059 }

Here is the call graph for this function:

Here is the caller graph for this function:

void Plo2d3RealToPixel	(	integer *	n1,
		integer *	n2,
		double *	x,
		double *	y,
		integer *	xm,
		integer *	ym,
		char *	xf
	)

Definition at line 2061 of file Plo2dEch.c.

References sciSubWindow::FRect, i, j, sciSubWindow::logflags, pSUBWIN_FEATURE, sciGetCurrentSubWin(), XLogScale(), XScale(), YLogScale(), and YScale().

Referenced by drawPolylineEntity().

02062 {
02063   integer i,j;
02065   double y_zero = 0.;
02066   sciPointObj *  psubwin =  sciGetCurrentSubWin();
02067   sciSubWindow * ppsubwin = pSUBWIN_FEATURE(psubwin);
02068
02069   if(ppsubwin->logflags[1]=='l')
02070   {
02071     y_zero = ppsubwin->FRect[1];
02072   }
02073
02074
02075
02076   if ((int)strlen(xf) >= 3 && xf[2]=='l')
02077   {
02078     for ( i=0 ; i < (*n2) ; i++)
02079       for (j=0 ; j< (*n1) ; j++)
02080       {
02081         ym[2*i+1+2*(*n2)*j]= YScale(y_zero);
02082         ym[2*i+2*(*n2)*j]= YLogScale(y[i+(*n2)*j]);
02083       }
02084   }
02085   else
02086   {
02087     for ( i=0 ; i < (*n2) ; i++)
02088       for (j=0 ; j< (*n1) ; j++)
02089       {
02090         ym[2*i+1+2*(*n2)*j]= YScale(y_zero);
02091         ym[2*i+2*(*n2)*j]= YScale(y[i+(*n2)*j]);
02092       }
02093   }
02094
02096   switch (xf[0])
02097   {
02098   case 'e' :
02100     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02101       for (j=0 ; j< (*n1) ; j++)
02102       {
02103         for ( i=0 ; i < (*n2) ; i++)
02104         {
02105           xm[2*i+2*(*n2)*j]= XLogScale(i+1.0);
02106           xm[2*i+1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02107
02108         }
02109       }
02110     else
02111       for (j=0 ; j< (*n1) ; j++)
02112       {
02113         for ( i=0 ; i < (*n2) ; i++)
02114         {
02115           xm[2*i+2*(*n2)*j]= XScale((i+1.0));
02116           xm[2*i+1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02117
02118         }
02119       }
02120       break ;
02121   case 'o' :
02122     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02123       for (j=0 ; j< (*n1) ; j++)
02124       {
02125         for ( i=0 ; i < (*n2) ; i++)
02126         {
02127
02128           xm[2*i+2*(*n2)*j]= XLogScale(x[i]);
02129           xm[2*i+1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02130         }
02131       }
02132     else
02133       for (j=0 ; j< (*n1) ; j++)
02134       {
02135         for ( i=0 ; i < (*n2) ; i++)
02136         {
02137           xm[2*i+2*(*n2)*j]= XScale(x[i]);
02138           xm[2*i+1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02139
02140         }
02141       }
02142       break;
02143   case 'g' :
02144   default:
02145     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02146       for (j=0 ; j< (*n1) ; j++)
02147       {
02148         for ( i=0 ; i < (*n2) ; i++)
02149         {
02150           xm[2*i+2*(*n2)*j]= XLogScale(x[i+(*n2)*j]);
02151           xm[2*i+1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02152
02153         }
02154       }
02155     else
02156       for (j=0 ; j< (*n1) ; j++)
02157       {
02158         for ( i=0 ; i < (*n2) ; i++)
02159         {
02160           xm[2*i+2*(*n2)*j]= XScale(x[i+(*n2)*j]);
02161           xm[2*i+1+2*(*n2)*j]=xm[2*i+2*(*n2)*j];
02162         }
02163       }
02164       break;
02165   }
02166 }

Here is the call graph for this function:

Here is the caller graph for this function:

void Plo2d4RealToPixel	(	integer *	n1,
		integer *	n2,
		double *	x,
		double *	y,
		integer *	xm,
		integer *	ym,
		char *	xf
	)

Definition at line 2168 of file Plo2dEch.c.

References i, j, XLogScale(), XScale(), YLogScale(), and YScale().

Referenced by drawPolylineEntity().

02169 {
02170   integer i,j;
02172   if ((int)strlen(xf) >= 3 && xf[2]=='l')
02173   {
02174     for ( i=0 ; i < (*n2) ; i++)
02175       for (j=0 ; j< (*n1) ; j++)
02176         ym[2*i+2*(*n2)*j]= YLogScale(y[i+(*n2)*j]);
02177     for ( i=0 ; i < (*n2)-1 ; i++)
02178       for (j=0 ; j< (*n1) ; j++)
02179         ym[2*i+1+2*(*n2)*j]=      ym[2*i+2+2*(*n2)*j];
02180   }
02181   else
02182   {
02183     for ( i=0 ; i < (*n2) ; i++)
02184       for (j=0 ; j< (*n1) ; j++)
02185         ym[2*i+2*(*n2)*j]= YScale(y[i+(*n2)*j]);
02186     for ( i=0 ; i < (*n2)-1 ; i++)
02187       for (j=0 ; j< (*n1) ; j++)
02188         ym[2*i+1+2*(*n2)*j]=      ym[2*i+2+2*(*n2)*j];
02189
02190   }
02191
02193   switch (xf[0])
02194   {
02195   case 'e' :
02197     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02198     {
02199       for (j=0 ; j< (*n1) ; j++)
02200         for ( i=0 ; i < (*n2) ; i++)
02201           xm[2*i+2*(*n2)*j]= XLogScale(i+1.0);
02202       for (j=0 ; j< (*n1) ; j++)
02203         for ( i=0 ; i < (*n2)-1 ; i++)
02204           xm[2*i+1+2*(*n2)*j]=     xm[2*i+2+2*(*n2)*j];
02205     }
02206     else
02207     {
02208       for (j=0 ; j< (*n1) ; j++)
02209         for ( i=0 ; i < (*n2) ; i++)
02210           xm[2*i+2*(*n2)*j]= XScale((i+1.0));
02211       for (j=0 ; j< (*n1) ; j++)
02212         for ( i=0 ; i < (*n2)-1 ; i++)
02213           xm[2*i+1+2*(*n2)*j]=     xm[2*i+2+2*(*n2)*j];
02214     }
02215     break ;
02216   case 'o' :
02217     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02218     {
02219       for (j=0 ; j< (*n1) ; j++)
02220         for ( i=0 ; i < (*n2) ; i++)
02221           xm[2*i+2*(*n2)*j]= XLogScale(x[i]);
02222       for (j=0 ; j< (*n1) ; j++)
02223         for ( i=0 ; i < (*n2)-1 ; i++)
02224           xm[2*i+1+2*(*n2)*j]=     xm[2*i+2+2*(*n2)*j];
02225     }
02226     else
02227
02228     {
02229       for (j=0 ; j< (*n1) ; j++)
02230         for ( i=0 ; i < (*n2) ; i++)
02231           xm[2*i+2*(*n2)*j]= XScale(x[i]);
02232       for (j=0 ; j< (*n1) ; j++)
02233         for ( i=0 ; i < (*n2)-1 ; i++)
02234           xm[2*i+1+2*(*n2)*j]=     xm[2*i+2+2*(*n2)*j];
02235
02236     }
02237     break;
02238   case 'g' :
02239   default:
02240     if ((int)strlen(xf) >= 2 && xf[1]=='l')
02241     {
02242       for (j=0 ; j< (*n1) ; j++)
02243         for ( i=0 ; i < (*n2) ; i++)
02244           xm[2*i+2*(*n2)*j]= XLogScale(x[i+(*n2)*j]);
02245       for (j=0 ; j< (*n1) ; j++)
02246         for ( i=0 ; i < (*n2)-1 ; i++)
02247           xm[2*i+1+2*(*n2)*j]=     xm[2*i+2+2*(*n2)*j];
02248
02249     }
02250     else
02251     {
02252       for (j=0 ; j< (*n1) ; j++)
02253         for ( i=0 ; i < (*n2) ; i++)
02254           xm[2*i+2*(*n2)*j]= XScale(x[i+(*n2)*j]);
02255       for (j=0 ; j< (*n1) ; j++)
02256         for ( i=0 ; i < (*n2)-1 ; i++)
02257           xm[2*i+1+2*(*n2)*j]=  xm[2*i+2+2*(*n2)*j];
02258
02259     }
02260     break;
02261   }
02262 }

Here is the call graph for this function:

Here is the caller graph for this function:

void C2F() rect2d	(	double	x[],
		integer	x1[],
		integer *	n,
		char *	dir
	)

meme chose mais pour transformer des rectangles

double to integer (pixel) direction

Definition at line 949 of file Plo2dEch.c.

References Cscale, i, inint, wcscalelist::logflag, wcscalelist::Wscx1, wcscalelist::Wscy1, XLogScale(), XScale(), YLogScale(), and YScale().

Referenced by drawrectangle_1(), drawrectangles_1(), and sciIsClicked().

00950 {
00951   integer i;
00952   if (strcmp("f2i",dir)==0)
00953     {
00955       for ( i=0 ; i < (*n) ; i= i+4)
00956         {
00957           if ( Cscale.logflag[0] == 'n' )
00958             {
00959               x1[i]=  XScale(x[i]);
00960               x1[i+2]=inint( Cscale.Wscx1*( x[i+2]));
00961             }
00962           else
00963             {
00964               x1[i]= XLogScale(x[i]);
00965               x1[i+2]=inint( Cscale.Wscx1*(log10((x[i]+x[i+2])/x[i])));
00966             }
00967           if ( Cscale.logflag[1] == 'n' )
00968             {
00969               x1[i+1]= YScale(x[i+1]);
00970               x1[i+3]=inint( Cscale.Wscy1*( x[i+3]));
00971             }
00972           else
00973             {
00974               x1[i+1]= YLogScale(x[i+1]);
00975               x1[i+3]=inint( Cscale.Wscy1*(log10(x[i+1]/(x[i+1]-x[i+3]))));
00976             }
00977         }
00978     }
00979   else if (strcmp("i2f",dir)==0)
00980     {
00981       for ( i=0 ; i < (*n) ; i=i+4)
00982         {
00983           if ( Cscale.logflag[0] == 'n' )
00984             {
00985               x[i]= XPi2R(x1[i] );
00986               x[i+2]=x1[i+2]/Cscale.Wscx1;
00987             }
00988           else
00989             {
00990               x[i]=exp10( XPi2R(x1[i]));
00991               x[i+2]=exp10(XPi2R( x1[i]+x1[i+2] ));
00992               x[i+2] -= x[i];
00993             }
00994           if ( Cscale.logflag[1] == 'n' )
00995             {
00996               x[i+1]= YPi2R( x1[i+1]);
00997               x[i+3]=x1[i+3]/Cscale.Wscy1;
00998             }
00999           else
01000             {
01001               x[i+1]=exp10( YPi2R( x1[i+1]));
01002               x[i+3]=exp10( YPi2R( x1[i+3]+x1[i+1]));
01003               x[i+2] -= x[i+1];
01004             }
01005         }
01006     }
01007   else
01008     sciprint(" Wrong dir %s argument in echelle2d\r\n",dir);
01009 }

Here is the call graph for this function:

Here is the caller graph for this function:

void rectangleDouble2Pixel	(	sciPointObj *	parentSubWin,
		double	ulPoint[3],
		double	userSize[2],
		int	edgesX[4],
		int	edgesY[4]
	)

Give the position of the 4 corners of a rectangle in pixels given the position of its upper left point in user coordiantes and its size. It works in every axes mode (2D/3D, log, reverse).

Parameters:

	parentSubWin	Subwindow in which the rectangle is drawn.
	ulPoint	Coordinates of the upper left point of the rectangle in user coord.
	userSize	Width and height of the rectangle in user coord.
	edgesX	X coordinates of the resulting positions.
	edgesY	Y coordinates of the resulting positions.

Definition at line 1889 of file Plo2dEch.c.

References sciSubWindow::axes, HDouble2Pixel, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, ReverseDataFor3D(), trans3d(), WDouble2Pixel, XDouble2Pixel, and YDouble2Pixel.

Referenced by drawRectangleEntity().

01894 {
01895   sciSubWindow * ppSubWin = pSUBWIN_FEATURE( parentSubWin  ) ;
01896
01897   if ( ppSubWin->is3d )
01898   {
01899     double rectx[4],recty[4],rectz[4];
01900     int n = 4 ;
01901     rectx[0] = rectx[3] = ulPoint[0] ;
01902     rectx[1] = rectx[2] = ulPoint[0] + userSize[0] ;
01903     recty[0] = recty[1] = ulPoint[1] ;
01904     recty[2] = recty[3] = ulPoint[1] - userSize[1];
01905     rectz[0] = rectz[1] = rectz[2]= rectz[3] = ulPoint[2] ;
01906
01907     ReverseDataFor3D( parentSubWin, rectx, recty, rectz, n);
01908
01909     trans3d( parentSubWin,n,edgesX,edgesY,rectx,recty,rectz) ;
01910   }
01911   else
01912   {
01913     /* 2D mode */
01914     /* position of the upper left point of the rectangle with reverse axes. */
01915     double realPoint[2] ;
01916     int ulPointPix[2] ;
01917     int sizePix[2] ;
01918
01919     if ( ppSubWin->axes.reverse[0] )
01920     {
01921       realPoint[0] = ulPoint[0] + userSize[0] ;
01922     }
01923     else
01924     {
01925       realPoint[0] = ulPoint[0] ;
01926     }
01927
01928     if ( ppSubWin->axes.reverse[1] )
01929     {
01930       realPoint[1] = ulPoint[1] - userSize[1] ;
01931     }
01932     else
01933     {
01934       realPoint[1] = ulPoint[1] ;
01935     }
01936
01937     ulPointPix[0] = XDouble2Pixel( realPoint[0] ) ;
01938     ulPointPix[1] = YDouble2Pixel( realPoint[1] ) ;
01939
01940     /* Nouvelles fonctions de changement d'echelle pour les longueurs --> voir PloEch.h */
01941     sizePix[0] = WDouble2Pixel( ulPoint[0], userSize[0] ) ;
01942     /* for y we take the length from the bottom left corner */
01943     sizePix[1] = HDouble2Pixel( ulPoint[1] - userSize[1], userSize[1] ) ;
01944
01945     edgesX[0] = ulPointPix[0] ;
01946     edgesX[1] = ulPointPix[0] + sizePix[0]  ;
01947     edgesX[2] = ulPointPix[0] + sizePix[0]  ;
01948     edgesX[3] = ulPointPix[0] ;
01949
01950     edgesY[0] = ulPointPix[1] ;
01951     edgesY[1] = ulPointPix[1] ;
01952     edgesY[2] = ulPointPix[1] + sizePix[1]  ;
01953     edgesY[3] = ulPointPix[1] + sizePix[1]  ;
01954
01955   }
01956 }

Here is the call graph for this function:

Here is the caller graph for this function:

static int same_subwin	(	lsubwin_rect	,
		subwin_rect
	)			`[static]`

Definition at line 262 of file Plo2dEch.c.

References Abs.

Referenced by check_subwin_wcscale(), and Nsetscale2d().

00264 {
00265   if ( Abs(lsubwin_rect[0] - subwin_rect[0]) < 1.e-8
00266        && Abs(lsubwin_rect[1] - subwin_rect[1]) < 1.e-8
00267        && Abs(lsubwin_rect[2] - subwin_rect[2]) < 1.e-8
00268        && Abs(lsubwin_rect[3] - subwin_rect[3]) < 1.e-8 )
00269     return 1;
00270   else
00271     return 0;
00272 }

Here is the caller graph for this function:

static void scale_copy	(	WCScaleList *	s1,
		WCScaleList *	s2
	)			`[static]`

Definition at line 328 of file Plo2dEch.c.

References i, j, s1, and s2.

Referenced by Cscale2default(), get_scale_win(), new_wcscale(), and set_scale_win().

00329 {
00330   int i,j;
00331   s1->flag=s2->flag;
00332   s1->wdim[0]=  s2->wdim[0];
00333   s1->wdim[1]=  s2->wdim[1];
00334   for ( i = 0 ; i < 4 ; i++ )
00335   {
00336     s1->subwin_rect[i]=s2->subwin_rect[i];
00337     s1->frect[i]=s2->frect[i];
00338     s1->WIRect1[i]=s2->WIRect1[i];
00339     s1->Waaint1[i]=s2->Waaint1[i];
00340     s1->xtics[i]=s2->xtics[i];
00341     s1->ytics[i]=s2->ytics[i];
00342     s1->axis[i]=s2->axis[i];
00343   }
00344   for ( i = 0 ; i < 3 ; i++ )
00345   {
00346     for ( j = 0 ; j < 3 ; j++ )
00347     {
00348       s1->m[i][j] = s2->m[i][j] ;
00349     }
00350   }
00351   for (i=0; i< 6; i++ )
00352   {
00353     s1->bbox1[i] = s2->bbox1[i] ;
00354   }
00355   s1->Wxofset1=s2->Wxofset1;
00356   s1->Wyofset1=s2->Wyofset1;
00357   s1->Wscx1=s2->Wscx1;
00358   s1->Wscy1=s2->Wscy1;
00359   s1->logflag[0] = s2->logflag[0];
00360   s1->logflag[1] = s2->logflag[1];
00361 }

Here is the caller graph for this function:

void scizoom	(	double	bbox[4],
		sciPointObj *	pobj
	)

Definition at line 1794 of file Plo2dEch.c.

References C2F, graduate(), lmax(), lmin(), max, min, pSUBWIN_FEATURE, sciGetZooming(), and sciSetZooming().

Referenced by set_zoom_box_property().

01795 {
01796   sciPointObj *psousfen;
01797   double fmin,fmax,lmin,lmax;
01798   integer min,max,puiss,deux=2,dix=10;
01799   psousfen= pobj; /* ??? */
01800
01801   if ( !( sciGetZooming(pobj) ) )
01802   {
01803     sciSetZooming(psousfen, 1);
01804   }
01806   fmin=  bbox[0];
01807   fmax=  bbox[2];
01808   if( pSUBWIN_FEATURE (psousfen)->logflags[0] == 'n' )
01809   {
01810     C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01811     pSUBWIN_FEATURE(psousfen)->axes.xlim[2]=puiss;
01812     pSUBWIN_FEATURE (psousfen)->ZRect[0]=lmin;
01813     pSUBWIN_FEATURE (psousfen)->ZRect[2]=lmax;
01814   }
01815   else
01816   {
01817     pSUBWIN_FEATURE(psousfen)->axes.xlim[2]=0;
01818     pSUBWIN_FEATURE (psousfen)->ZRect[0]=fmin;
01819     pSUBWIN_FEATURE (psousfen)->ZRect[2]=fmax;
01820   }
01821
01822   fmin= bbox[1];
01823   fmax= bbox[3];
01824   if ( pSUBWIN_FEATURE (psousfen)->logflags[1] == 'n' )
01825   {
01826     C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01827     pSUBWIN_FEATURE(psousfen)->axes.ylim[2]=puiss;
01828     pSUBWIN_FEATURE (psousfen)->ZRect[1]=lmin;
01829     pSUBWIN_FEATURE (psousfen)->ZRect[3]=lmax;
01830   }
01831   else
01832   {
01833     pSUBWIN_FEATURE(psousfen)->axes.ylim[2]=0;
01834     pSUBWIN_FEATURE (psousfen)->ZRect[1]=fmin;
01835     pSUBWIN_FEATURE (psousfen)->ZRect[3]=fmax;
01836   }
01837
01838   /* default values when zooming in 3d */
01839   /* and scizoom takes only xmin ymin xmax ymax AND not zmin zmax (for now at least) */
01840   /* F.Leray 29.09.05 */
01841   pSUBWIN_FEATURE (psousfen)->ZRect[4] = pSUBWIN_FEATURE (psousfen)->SRect[4];
01842   pSUBWIN_FEATURE (psousfen)->ZRect[5] = pSUBWIN_FEATURE (psousfen)->SRect[5];
01843
01844 }

Here is the call graph for this function:

Here is the caller graph for this function:

void set_scale	(	char	flag[6],
		double	subwin[4],
		double	frame_values[4],
		integer	aaint[4],
		char	logflag[3],
		double	axis_values[4]
	)

Definition at line 632 of file Plo2dEch.c.

References C2F, Cscale, dr(), i, L, PD0, PI0, wcscalelist::subwin_rect, and wcscalelist::wdim.

Referenced by DrawAxes(), drawSubWinEntity(), Nsetscale2d(), sci_draw(), sciInitSelectedSubWin(), sciIsClicked(), set_axes_bounds_property(), SetEch3d1(), setscale2d(), updateScale3d(), and updateSubWinScale().

00644 {
00645   char c;
00646   char wdim_changed= 'f',subwin_changed='f';
00647   char frame_values_changed='f',aaint_changed='f';
00648   char logflag_changed='f';
00649   char axis_changed = 'f';
00650   integer  verbose=0,narg,wdim[2];
00651   int i;
00652   if ( flag[0] == 't'  )
00653     {
00654       C2F(dr)("xget","wdim",&verbose,wdim,&narg, PI0, PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
00655       if ( Cscale.wdim[0] != wdim[0] || Cscale.wdim[1] != wdim[1])
00656         {
00657           Cscale.wdim[0] = wdim[0]; Cscale.wdim[1] = wdim[1];
00658           wdim_changed='t';
00659         }
00660     }
00661   if ( flag[1] == 't' )
00662     {
00663       for (i=0; i < 4 ; i++ )
00664         if ( subwin[i] != Cscale.subwin_rect[i]) { subwin_changed='t' ; break;}
00665     }
00666   if ( flag[2] == 't' )
00667     {
00668       for (i=0; i < 4 ; i++ )
00669         if ( frame_values[i] != Cscale.frect[i]) { frame_values_changed='t' ; break;}
00670       /* if no scales were present and the values given are the same as the
00671        * default frect values we must register that we are setting a scale
00672        */
00673       if ( Cscale.flag == 0) frame_values_changed='t' ;
00674     }
00675   if ( flag[3] == 't' )
00676     {
00677       for (i=0; i < 4 ; i++ )
00678         if ( aaint[i] != Cscale.Waaint1[i]) { aaint_changed='t' ; break;}
00679     }
00680   if ( flag[4] == 't' )
00681     {
00682       for (i=0; i < 2 ; i++ )
00683         if ( logflag[i] != Cscale.logflag[i]) { logflag_changed='t' ; break;}
00684     }
00685   if ( flag[5] == 't' )
00686     {
00687       for (i=0; i < 4 ; i++ )
00688         if ( axis_values[i] != Cscale.axis[i]) { axis_changed='t' ; break;}
00689     }
00690   if ( axis_changed == 't')
00691     {
00692       for (i=0; i < 4 ; i++ ) Cscale.axis[i] = axis_values[i];
00693     }
00694
00695   if ( subwin_changed == 't' )
00696     {
00697       for (i=0; i < 4 ; i++ ) Cscale.subwin_rect[i] = subwin[i];
00698     }
00699   if ( frame_values_changed == 't' )
00700     {
00701       for (i=0; i < 4 ; i++) Cscale.frect[i]=frame_values[i];
00702       /* the scale is no more a default scale */
00703       Cscale.flag = 1;
00704     }
00705   if ( wdim_changed == 't' || subwin_changed == 't' || frame_values_changed == 't'
00706        ||  axis_changed == 't' )
00707     {
00708       /* Upgrading constants for 2D transformation */
00709       double scx,scy,xoff,yoff,val;
00710
00711       sciPointObj *pobj = sciGetCurrentSubWin();
00712       sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
00713
00714       scx =  ((double) Cscale.wdim[0]*Cscale.subwin_rect[2]-Cscale.wdim[0]*Cscale.subwin_rect[2]
00715               *(Cscale.axis[0]+Cscale.axis[1]));
00716       scy =  ((double) Cscale.wdim[1]*Cscale.subwin_rect[3]-Cscale.wdim[1]*Cscale.subwin_rect[3]
00717               *(Cscale.axis[2]+Cscale.axis[3]));
00718       xoff= ((double) Cscale.wdim[0]*Cscale.subwin_rect[2])*(Cscale.axis[0]);
00719       yoff= ((double) Cscale.wdim[1]*Cscale.subwin_rect[3])*(Cscale.axis[2]);
00720
00721       Cscale.Wxofset1= xoff+Cscale.subwin_rect[0]*((double)Cscale.wdim[0]);
00722       Cscale.Wyofset1= yoff+Cscale.subwin_rect[1]*((double)Cscale.wdim[1]);
00723       Cscale.Wscx1   = scx;
00724       Cscale.Wscy1   = scy;
00725
00726       val = Abs(Cscale.frect[0]- Cscale.frect[2]);
00727       Cscale.Wscx1 = (val <=SMDOUBLE) ? Cscale.Wscx1/SMDOUBLE : Cscale.Wscx1/val;
00728       val = Abs(Cscale.frect[1]- Cscale.frect[3]);
00729       Cscale.Wscy1 = (val <=SMDOUBLE) ? Cscale.Wscy1/SMDOUBLE : Cscale.Wscy1/val;
00730
00731       /*          F.Leray 12.10.04 : MODIF named scale_modification*/
00732       if(ppsubwin->axes.reverse[0]==TRUE && ppsubwin->is3d == FALSE)
00733       {
00734         Cscale.WIRect1[0] = XScale( Cscale.frect[2]);
00735         Cscale.WIRect1[2] = Abs(XScale( Cscale.frect[2]) -  XScale( Cscale.frect[0]));
00736       }
00737       else
00738       {
00739         Cscale.WIRect1[0] = XScale( Cscale.frect[0]);
00740         Cscale.WIRect1[2] = Abs(XScale( Cscale.frect[2]) -  XScale( Cscale.frect[0]));
00741       }
00742
00743       if(ppsubwin->axes.reverse[1]==TRUE && ppsubwin->is3d == FALSE)
00744       {
00745         Cscale.WIRect1[1] = YScale( Cscale.frect[1]);
00746         Cscale.WIRect1[3] = Abs(YScale( Cscale.frect[3]) -  YScale( Cscale.frect[1]));
00747       }
00748       else
00749       {
00750         Cscale.WIRect1[1] = YScale( Cscale.frect[3]);
00751         Cscale.WIRect1[3] = Abs(YScale( Cscale.frect[3]) -  YScale( Cscale.frect[1]));
00752       }
00753     }
00754   if (  aaint_changed== 't' )
00755     {
00756       for (i=0; i < 4 ; i++) Cscale.Waaint1[i]=aaint[i];
00757     }
00758   if ( logflag_changed== 't' )
00759     {
00760       Cscale.logflag[0]=logflag[0];      Cscale.logflag[1]=logflag[1];
00761     }
00762   if (  aaint_changed== 't' || frame_values_changed == 't')
00763     {
00764       Cscale.xtics[0] = Cscale.frect[0];
00765       Cscale.xtics[1] = Cscale.frect[2];
00766       Cscale.ytics[0] = Cscale.frect[1];
00767       Cscale.ytics[1] = Cscale.frect[3];
00768       Cscale.xtics[2] = 0.0;
00769       Cscale.ytics[2] = 0.0;
00770       Cscale.xtics[3] = Cscale.Waaint1[1];
00771       Cscale.ytics[3] = Cscale.Waaint1[3];
00772     }
00773
00775   if ( (c=GetDriver()) == 'X' ||  c == 'R' || c == 'I' || c == 'G' || c == 'W' )
00776     {
00777       set_window_scale(curwin(),&Cscale);
00778     }
00779 }

Here is the call graph for this function:

Here is the caller graph for this function:

static void set_scale_win	(	ScaleList **	listptr,
		integer	i,
		WCScaleList *	scale
	)			`[static]`

Definition at line 175 of file Plo2dEch.c.

References check_subwin_wcscale(), MALLOC, new_wcscale(), wcscalelist::next, NULL, wcscalelist::prev, scale, scale_copy(), and sciprint().

Referenced by set_window_scale().

00179 {
00180   if ( *listptr == (ScaleList  *) NULL)
00181     {
00182       /* window i does not exist add an entry for it */
00183       if ((*listptr = (ScaleList *) MALLOC( sizeof (ScaleList)))==0)
00184         {
00185           sciprint("AddWindowScale_ memory exhausted\n");
00186           return;
00187         }
00188       else
00189         {
00190           (*listptr)->Win  = i;
00191           (*listptr)->next = (ScaleList *) NULL ;
00192           (*listptr)->scales = new_wcscale(scale);
00193           if ( (*listptr)->scales == 0)
00194             {
00195               *listptr = 0;
00196               sciprint("AddWindowScale_ memory exhausted\n");
00197             }
00198           return ;
00199         }
00200     }
00201   if ( (*listptr)->Win == i)
00202     {
00203       /* try to find a scale for Cscale.subwin_rect for window i */
00204       WCScaleList *loc = check_subwin_wcscale((*listptr)->scales,scale->subwin_rect);
00205       if ( loc != NULL)
00206         {
00207           /* subwin exists we update it */
00208           scale_copy(loc,scale);
00209           /* we move loc to the top of the list */
00210           if ( loc != (*listptr)->scales )
00211             {
00212               (loc->prev)->next = loc->next ;
00213               if ( loc->next != NULL) (loc->next)->prev = loc->prev ;
00214               loc->next = (*listptr)->scales;
00215               loc->next->prev = loc ;
00216               (*listptr)->scales = loc;
00217             }
00218         }
00219       else
00220         {
00221           /* subwin does not exists we add it a the begining of the list */
00222           if (( loc = new_wcscale(scale))== NULL)
00223             {
00224               sciprint("AddWindowScale_ memory exhausted\n");
00225               return ;
00226             }
00227           else
00228             {
00229               loc->next = (*listptr)->scales;
00230               if (loc->next != NULL) loc->next->prev = loc;
00231               (*listptr)->scales = loc;
00232             }
00233         }
00234     }
00235   else
00236     set_scale_win( &((*listptr)->next),i,scale);
00237 }

Here is the call graph for this function:

Here is the caller graph for this function:

static void set_window_scale	(	integer	i,
		WCScaleList *	scale
	)			`[static]`

Definition at line 168 of file Plo2dEch.c.

References L, Max, scale, set_scale_win(), and The_List.

Referenced by Cscale2default(), Nsetscale2d(), and set_window_scale_with_default().

00171 {
00172   set_scale_win(&The_List,Max(0L,i),scale);
00173 }

Here is the call graph for this function:

Here is the caller graph for this function:

void set_window_scale_with_default ( int i )

Definition at line 110 of file Plo2dEch.c.

References Defscale, and set_window_scale().

Referenced by CleanPlots().

00110 { set_window_scale(i,&Defscale);}

Here is the call graph for this function:

Here is the caller graph for this function:

int C2F() setscale2d	(	WRect	,
		FRect	,
		char *	logscale,
		integer	l1
	)

Definition at line 422 of file Plo2dEch.c.

References NULL, and set_scale().

Referenced by cmscope(), and cscope().

00426 {
00427   static integer aaint[]={2,10,2,10};
00428   if (logscale[0]=='l')
00429     {
00430       FRect[0]=log10(FRect[0]);
00431       FRect[2]=log10(FRect[2]);
00432     }
00433   if (logscale[1]=='l')
00434     {
00435       FRect[1]=log10(FRect[1]);
00436       FRect[3]=log10(FRect[3]);
00437     }
00438   set_scale("tttftf",WRect,FRect,aaint,logscale,NULL);
00439   return(0);
00440 }

Here is the call graph for this function:

Here is the caller graph for this function:

static void show_scales ( ScaleList * listptr ) [static]

Definition at line 391 of file Plo2dEch.c.

References wcscalelist::flag, wcscalelist::next, NULL, sciprint(), and wcscalelist::subwin_rect.

Referenced by ShowScales().

00393 {
00394   if (listptr != (ScaleList  *) NULL)
00395     {
00396       WCScaleList *loc = listptr->scales;
00397       sciprint("Window %d \r\n",listptr->Win);
00398       while ( loc != NULL)
00399         {
00400           sciprint("\tsubwin=[%5.2f,%5.2f,%5.2f,%5.2f], flag=%d\r\n",
00401                    loc->subwin_rect[0],loc->subwin_rect[1],loc->subwin_rect[2],loc->subwin_rect[3],
00402                    loc->flag);
00403           loc = loc->next ;
00404         }
00405       show_scales(listptr->next);
00406     }
00407 }

Here is the call graph for this function:

Here is the caller graph for this function:

void ShowScales ( void )

Definition at line 380 of file Plo2dEch.c.

References Cscale, wcscalelist::flag, sciprint(), show_scales(), wcscalelist::subwin_rect, and The_List.

Referenced by sci_xsetech().

00381 {
00382   sciprint("-----------scales-------------\r\n");
00383   show_scales(The_List);
00384   sciprint("----------current scale-------\r\n");
00385   sciprint("\tsubwin=[%5.2f,%5.2f,%5.2f,%5.2f], flag=%d\r\n",
00386            Cscale.subwin_rect[0],Cscale.subwin_rect[1],Cscale.subwin_rect[2],Cscale.subwin_rect[3],
00387            Cscale.flag);
00388   sciprint("-----------end----------------\r\n");
00389 }

Here is the call graph for this function:

Here is the caller graph for this function:

int StoreCommand ( char * command )

Definition at line 82 of file dynamic_menus.c.

00083 {
00084         return (StoreCommand1 (command, 0)); /* jpc 1->0 */
00085 }

void unzoom ( void )

Definition at line 1372 of file Plo2dEch.c.

References C2F, dr1(), graduate(), L, lmax(), lmin(), max, min, NULL, PD0, PI0, tagSons::pnext, tagSons::pointobj, pSUBWIN_FEATURE, SCI_SUBWIN, sciDrawObj(), sciGetCurrentFigure(), sciGetEntityType(), sciGetSons(), sciGetZooming(), and sciSetZooming().

Referenced by sci_unzoom(), scig_unzoom(), set_zoom_box_property(), and set_zoom_state_property().

01373 {
01374   integer ww,verbose=0,narg;
01376   double fmin,fmax,lmin,lmax;
01377   integer min,max,puiss,deux=2,dix=10;
01378   sciPointObj *psousfen;
01379   sciSons *psonstmp;
01380
01381
01382   C2F(dr1)("xclear","v",PI0,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01383   C2F(dr1)("xget","window",&verbose,&ww,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01384   /***** 02/10/2002 ****/
01385   psonstmp = sciGetSons (sciGetCurrentFigure());
01386   while (psonstmp != (sciSons *) NULL)
01387   {
01388     if(sciGetEntityType (psonstmp->pointobj) == SCI_SUBWIN)
01389     {
01390       psousfen= (sciPointObj *)psonstmp->pointobj;
01391       if (sciGetZooming(psousfen))
01392       {
01393         sciSetZooming(psousfen, 0);
01394         /*   pSUBWIN_FEATURE (psousfen)->ZRect[0]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[0]; */
01395         /*                    pSUBWIN_FEATURE (psousfen)->ZRect[1]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[1]; */
01396         /*                    pSUBWIN_FEATURE (psousfen)->ZRect[2]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[2]; */
01397         /*                    pSUBWIN_FEATURE (psousfen)->ZRect[3]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[3]; */
01398
01399         pSUBWIN_FEATURE (psousfen)->ZRect[0]   = pSUBWIN_FEATURE (psousfen)->SRect[0];
01400         pSUBWIN_FEATURE (psousfen)->ZRect[1]   = pSUBWIN_FEATURE (psousfen)->SRect[1];
01401         pSUBWIN_FEATURE (psousfen)->ZRect[2]   = pSUBWIN_FEATURE (psousfen)->SRect[2];
01402         pSUBWIN_FEATURE (psousfen)->ZRect[3]   = pSUBWIN_FEATURE (psousfen)->SRect[3];
01403
01404         /*}  SS: moved below because if sciGetZooming(psousfen)==0
01405         ZRect is undefined -> code may enter in infinite recursion loop to compute graduation
01406         and there is no use to regraduate */
01407
01409         fmin= pSUBWIN_FEATURE (psousfen)->ZRect[0];
01410         fmax= pSUBWIN_FEATURE (psousfen)->ZRect[2];
01411         C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01412         pSUBWIN_FEATURE(psousfen)->axes.xlim[2]=puiss;
01413
01414         fmin= pSUBWIN_FEATURE (psousfen)->ZRect[1];
01415         fmax= pSUBWIN_FEATURE (psousfen)->ZRect[3];
01416         C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01417         pSUBWIN_FEATURE(psousfen)->axes.ylim[2]=puiss;
01418         /*****/
01419       }
01420     }
01421     psonstmp = psonstmp->pnext;
01422   }
01423
01424   sciDrawObj(sciGetCurrentFigure());
01425 }

Here is the call graph for this function:

Here is the caller graph for this function:

void unzoom_one_axes ( sciPointObj * psousfen )

Definition at line 1427 of file Plo2dEch.c.

References C2F, graduate(), lmax(), lmin(), max, min, pSUBWIN_FEATURE, SCI_SUBWIN, sciDrawObj(), sciGetCurrentFigure(), sciGetEntityType(), sciGetZooming(), and sciSetZooming().

Referenced by sci_unzoom().

01428 {
01429   double fmin,fmax,lmin,lmax;
01430   integer min,max,puiss,deux=2,dix=10;
01431
01432   if (sciGetEntityType (psousfen) == SCI_SUBWIN) {
01433     if (sciGetZooming(psousfen))        {
01434       sciSetZooming(psousfen, 0);
01435       /*   pSUBWIN_FEATURE (psousfen)->ZRect[0]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[0]; */
01436       /*          pSUBWIN_FEATURE (psousfen)->ZRect[1]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[1]; */
01437       /*          pSUBWIN_FEATURE (psousfen)->ZRect[2]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[2]; */
01438       /*          pSUBWIN_FEATURE (psousfen)->ZRect[3]   = pSUBWIN_FEATURE (psousfen)->ZRect_kp[3]; */
01439
01440       pSUBWIN_FEATURE (psousfen)->ZRect[0]   = pSUBWIN_FEATURE (psousfen)->SRect[0];
01441       pSUBWIN_FEATURE (psousfen)->ZRect[1]   = pSUBWIN_FEATURE (psousfen)->SRect[1];
01442       pSUBWIN_FEATURE (psousfen)->ZRect[2]   = pSUBWIN_FEATURE (psousfen)->SRect[2];
01443       pSUBWIN_FEATURE (psousfen)->ZRect[3]   = pSUBWIN_FEATURE (psousfen)->SRect[3];
01444
01445     }
01446
01448     fmin= pSUBWIN_FEATURE (psousfen)->ZRect[0];
01449     fmax= pSUBWIN_FEATURE (psousfen)->ZRect[2];
01450     C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01451     pSUBWIN_FEATURE(psousfen)->axes.xlim[2]=puiss;
01452
01453     fmin= pSUBWIN_FEATURE (psousfen)->ZRect[1];
01454     fmax= pSUBWIN_FEATURE (psousfen)->ZRect[3];
01455     C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01456     pSUBWIN_FEATURE(psousfen)->axes.ylim[2]=puiss;
01457
01458     sciDrawObj(sciGetCurrentFigure());
01459   }
01460 }

Here is the call graph for this function:

Here is the caller graph for this function:

void xclick_2	(	char *	fname,
		char *	str,
		integer *	ibutton,
		integer *	iflag,
		integer *	istr,
		integer *	x1,
		integer *	yy1,
		integer *	x7,
		double *	x,
		double *	y,
		double *	dx3,
		double *	dx4,
		integer	lx0,
		integer	lx1
	)

Definition at line 445 of file Xcall1.c.

References C2F, dr(), echelle2d(), L, n, and PD0.

Referenced by zoom_get_rectangle().

00446 {
00447   integer n=1;
00448   C2F(dr)(fname,str,ibutton,x1,yy1,iflag,istr,x7,PD0,PD0,dx3,dx4,lx0,lx1);
00449   if (*ibutton != -100) C2F(echelle2d)(x,y,x1,yy1,&n,&n,"i2f",3L);
00450 }

Here is the call graph for this function:

Here is the caller graph for this function:

double XDPi2R ( double x )

Definition at line 1650 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, wcscalelist::frect, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscx1, and wcscalelist::Wxofset1.

01651 {
01652   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01653   sciPointObj *pobj = sciGetCurrentSubWin();
01654   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01655
01656   if(ppsubwin->axes.reverse[0]==TRUE && ppsubwin->is3d == FALSE)
01657     return Cscale.frect[2] - (1.0/Cscale.Wscx1)*((x) - Cscale.Wxofset1);
01658   else
01659     return Cscale.frect[0] + (1.0/Cscale.Wscx1)*((x) - Cscale.Wxofset1);
01660
01661
01662   sciprint("Error in XScale\n");
01663   return -9000;
01664 }

Here is the call graph for this function:

int C2F() xechelle2d	(	x	,
		x1	,
		*	n1,
		dir	,
		integer	lstr
	)

Definition at line 793 of file Plo2dEch.c.

References Cscale, i, wcscalelist::logflag, sciprint(), x, XLogScale(), XPi2R(), and XScale().

Referenced by echelle2d().

00798 {
00799   integer i;
00800   if (strcmp("f2i",dir)==0)
00801   {
00802
00803     if (Cscale.logflag[0] == 'n')
00804       for ( i=0 ; i < (*n1) ; i++) x1[i]= XScale(x[i]);
00805     else
00806       for ( i=0 ; i < (*n1) ; i++) x1[i]= XLogScale(x[i]);
00807   }
00808   else if (strcmp("i2f",dir)==0)
00809   {
00810     if (Cscale.logflag[0] == 'n')
00811       for ( i=0 ; i < (*n1) ; i++) x[i]= XPi2R( x1[i] );
00812     else
00813       for ( i=0 ; i < (*n1) ; i++) x[i]= exp10(XPi2R( x1[i]));
00814   }
00815   else
00816     sciprint(" Wrong dir %s argument in echelle2d\r\n",dir);
00817
00818   return(0);
00819 }

Here is the call graph for this function:

Here is the caller graph for this function:

void xgetmouse2	(	char *	fname,
		char *	str,
		integer *	ibutton,
		integer *	iflag,
		integer *	x1,
		integer *	yy1,
		integer *	x6,
		integer *	x7,
		double *	x,
		double *	y,
		double *	dx3,
		double *	dx4,
		integer	lx0,
		integer	lx1
	)

Definition at line 480 of file Xcall1.c.

References C2F, dr(), echelle2d(), L, n, and PD0.

Referenced by zoom_get_rectangle().

00481 {
00482   integer n=1;
00483   C2F(dr)(fname,str,ibutton,x1,yy1,iflag,x6,x7,PD0,PD0,dx3,dx4,lx0,lx1);
00484
00485   if (*ibutton != -100) C2F(echelle2d)(x,y,x1,yy1,&n,&n,"i2f",3L);
00486 }

Here is the call graph for this function:

Here is the caller graph for this function:

int XLogScale ( double x )

Definition at line 1553 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, wcscalelist::frect, inint, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscx1, and wcscalelist::Wxofset1.

Referenced by Plo2d2RealToPixel(), Plo2d3RealToPixel(), Plo2d4RealToPixel(), rect2d(), and xechelle2d().

01554 {
01555   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01556
01557   sciPointObj *pobj = sciGetCurrentSubWin();
01558   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01559
01560   if(ppsubwin->axes.reverse[0]==TRUE && ppsubwin->is3d == FALSE)
01561     return inint( Cscale.Wscx1*(Cscale.frect[2] - log10(x)) + Cscale.Wxofset1);
01562   else
01563     return inint( Cscale.Wscx1*(log10(x) -Cscale.frect[0]) + Cscale.Wxofset1);
01564
01565
01566   sciprint("Error in XLogScale\n");
01567   return -9000;
01568 }

Here is the call graph for this function:

Here is the caller graph for this function:

double XPi2R ( int x )

Definition at line 1616 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, wcscalelist::frect, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscx1, and wcscalelist::Wxofset1.

Referenced by drawSegsEntity(), ellipse2d(), and xechelle2d().

01617 {
01618   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01619
01620   sciPointObj *pobj = sciGetCurrentSubWin();
01621   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01622
01623   if(ppsubwin->axes.reverse[0]==TRUE && ppsubwin->is3d == FALSE)
01624     return Cscale.frect[2] - (1.0/Cscale.Wscx1)*((x) - Cscale.Wxofset1);
01625   else
01626     return Cscale.frect[0] + (1.0/Cscale.Wscx1)*((x) - Cscale.Wxofset1);
01627
01628
01629   sciprint("Error in XScale\n");
01630   return -9000;
01631 }

Here is the call graph for this function:

Here is the caller graph for this function:

int XScale ( double x )

Definition at line 1523 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, FLOAT_2_INT, wcscalelist::frect, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscx1, and wcscalelist::Wxofset1.

Referenced by axis2d(), axis_3ddraw(), box3d(), checkXAxes2dTics(), checkYAxes2dTics(), Convex_Box(), DrawAxis(), drawFecEntity(), drawGrayplotEntity(), drawSegsEntity(), DrawXGrid(), DrawXSubTics(), DrawXTics(), DrawYGrid(), DrawYSubTics(), DrawYTics(), ellipse2d(), Plo2d2RealToPixel(), Plo2d3RealToPixel(), Plo2d4RealToPixel(), rect2d(), Sci_Axis(), sciChamp2DRealToPixel(), XDrawAxisLine(), xechelle2d(), and YDrawAxisLine().

01524 {
01525   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01526
01527   sciPointObj *pobj = sciGetCurrentSubWin();
01528   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01529
01530   if(ppsubwin->axes.reverse[0]==TRUE && ppsubwin->is3d == FALSE)
01531   {
01532
01533     /* 2147483647 == 2^31 - 1 == INT32MAX */
01534     /*return inint( Max( Min(Cscale.Wscx1*(Cscale.frect[2] - (x)) + Cscale.Wxofset1, INT_MAX ), INT_MIN ) ) ;*/
01535     double dRes = Cscale.Wscx1 * (Cscale.frect[2] - (x)) + Cscale.Wxofset1 ;
01536     return FLOAT_2_INT( dRes ) ;
01537   }
01538   else
01539   {
01540     /*return inint( Max( Min(Cscale.Wscx1*((x) -Cscale.frect[0]) + Cscale.Wxofset1, INT_MAX ), INT_MIN ) );*/
01541     double dRes = Cscale.Wscx1 * ((x) -Cscale.frect[0]) + Cscale.Wxofset1 ;
01542     return FLOAT_2_INT( dRes ) ;
01543   }
01544
01545
01546   sciprint("Error in XScale\n");
01547   return -9000;
01548 }

Here is the call graph for this function:

Here is the caller graph for this function:

double YDPi2R ( double y )

Definition at line 1667 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, wcscalelist::frect, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscy1, and wcscalelist::Wyofset1.

01668 {
01669   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01670   sciPointObj *pobj = sciGetCurrentSubWin();
01671   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01672
01673   if(ppsubwin->axes.reverse[1]==TRUE && ppsubwin->is3d == FALSE)
01674     return Cscale.frect[1] + (1.0/Cscale.Wscy1)*((y) - Cscale.Wyofset1);
01675   else
01676     return Cscale.frect[3] - (1.0/Cscale.Wscy1)*((y) - Cscale.Wyofset1);
01677
01678
01679
01680   sciprint("Error in YScale\n");
01681   return -9000;
01682 }

Here is the call graph for this function:

int C2F() yechelle2d	(	y	,
		yy1	,
		*	n2,
		dir	,
		integer	lstr
	)

Definition at line 823 of file Plo2dEch.c.

References Cscale, i, wcscalelist::logflag, sciprint(), YLogScale(), YPi2R(), and YScale().

Referenced by echelle2d().

00828 {
00829   integer i;
00830   if (strcmp("f2i",dir)==0)
00831   {
00832     if (Cscale.logflag[1] == 'n')
00833       for ( i=0 ; i < (*n2) ; i++) yy1[i]= YScale(y[i]);
00834     else
00835       for ( i=0 ; i < (*n2) ; i++) yy1[i]= YLogScale(y[i]);
00836   }
00837   else if (strcmp("i2f",dir)==0)
00838   {
00839     if (Cscale.logflag[1] == 'n')
00840       for ( i=0 ; i < (*n2) ; i++)  y[i]= YPi2R( yy1[i] );
00841     else
00842       for ( i=0 ; i < (*n2) ; i++)  y[i]= exp10(YPi2R( yy1[i]));
00843   }
00844   else
00845     sciprint(" Wrong dir %s argument in echelle2d\r\n",dir);
00846
00847   return(0);
00848 }

Here is the call graph for this function:

Here is the caller graph for this function:

int YLogScale ( double y )

Definition at line 1597 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, wcscalelist::frect, inint, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscy1, and wcscalelist::Wyofset1.

Referenced by Plo2d2RealToPixel(), Plo2d3RealToPixel(), Plo2d4RealToPixel(), rect2d(), and yechelle2d().

01598 {
01599   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01600   sciPointObj *pobj = sciGetCurrentSubWin();
01601   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01602
01603   if(ppsubwin->axes.reverse[1]==TRUE && ppsubwin->is3d == FALSE)
01604     return inint( Cscale.Wscy1*(log10(y)-Cscale.frect[1]) + Cscale.Wyofset1);
01605   else
01606     return inint( Cscale.Wscy1*(-log10(y)+Cscale.frect[3]) + Cscale.Wyofset1);
01607
01608
01609
01610   sciprint("Error in YLogScale\n");
01611   return -9000;
01612 }

Here is the call graph for this function:

Here is the caller graph for this function:

double YPi2R ( int y )

Definition at line 1634 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FALSE, wcscalelist::frect, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscy1, and wcscalelist::Wyofset1.

Referenced by drawSegsEntity(), ellipse2d(), and yechelle2d().

01635 {
01636   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01637   sciPointObj *pobj = sciGetCurrentSubWin();
01638   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01639
01640   if(ppsubwin->axes.reverse[1]==TRUE && ppsubwin->is3d == FALSE)
01641     return Cscale.frect[1] + (1.0/Cscale.Wscy1)*((y) - Cscale.Wyofset1);
01642   else
01643     return Cscale.frect[3] - (1.0/Cscale.Wscy1)*((y) - Cscale.Wyofset1);
01644
01645
01646   sciprint("Error in YScale\n");
01647   return -9000;
01648 }

Here is the call graph for this function:

Here is the caller graph for this function:

int YScale ( double y )

Definition at line 1573 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, FLOAT_2_INT, wcscalelist::frect, sciSubWindow::is3d, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), wcscalelist::Wscy1, and wcscalelist::Wyofset1.

Referenced by axis2d(), axis_3ddraw(), box3d(), checkXAxes2dTics(), checkYAxes2dTics(), Convex_Box(), DrawAxis(), drawFecEntity(), drawGrayplotEntity(), drawSegsEntity(), DrawXGrid(), DrawXSubTics(), DrawXTics(), DrawYGrid(), DrawYSubTics(), DrawYTics(), ellipse2d(), Plo2d2RealToPixel(), Plo2d3RealToPixel(), Plo2d4RealToPixel(), rect2d(), Sci_Axis(), sciChamp2DRealToPixel(), XDrawAxisLine(), YDrawAxisLine(), and yechelle2d().

01574 {
01575   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01576
01577   sciPointObj *pobj = sciGetCurrentSubWin();
01578   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01579
01580   if( ppsubwin->axes.reverse[1] && !ppsubwin->is3d )
01581   {
01582     double dRes = Cscale.Wscy1 * ( y - Cscale.frect[1] ) + Cscale.Wyofset1 ;
01583     return FLOAT_2_INT( dRes ) ;
01584   }
01585   else
01586   {
01587     double dRes = Cscale.Wscy1 * ( -y + Cscale.frect[3] ) + Cscale.Wyofset1 ;
01588     return FLOAT_2_INT( dRes ) ;
01589   }
01590
01591
01592   sciprint("Error in YScale\n");
01593   return -9000;
01594 }

Here is the call graph for this function:

Here is the caller graph for this function:

int zoom ( void )

Definition at line 1360 of file Plo2dEch.c.

References zoom_box(), and zoom_get_rectangle().

Referenced by sci_zoom_rect(), and scig_2dzoom().

01361 {
01362   double bbox[4];
01363   int x_pixel[2], y_pixel[2];
01364
01365   if ( zoom_get_rectangle(bbox,x_pixel,y_pixel) == 1 ) { return 1 ; }
01366
01367   zoom_box(bbox,x_pixel,y_pixel);
01368   return 0;
01369 }

Here is the call graph for this function:

Here is the caller graph for this function:

double Zoom3d_XPi2R ( int x )

Definition at line 1684 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, wcscalelist::frect, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscx1, and wcscalelist::Wxofset1.

01685 {
01686   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01687   sciPointObj *pobj = sciGetCurrentSubWin();
01688   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01689
01690   if(ppsubwin->axes.reverse[0]==TRUE) /* difference is HERE */
01691     return Cscale.frect[2] - (1.0/Cscale.Wscx1)*((x) - Cscale.Wxofset1);
01692   else
01693     return Cscale.frect[0] + (1.0/Cscale.Wscx1)*((x) - Cscale.Wxofset1);
01694
01695
01696   sciprint("Error in Zoom3d_XScale\n");
01697   return -9000;
01698 }

Here is the call graph for this function:

double Zoom3d_YPi2R ( int y )

Definition at line 1701 of file Plo2dEch.c.

References sciSubWindow::axes, Cscale, wcscalelist::frect, pSUBWIN_FEATURE, AXES::reverse, sciGetCurrentSubWin(), sciprint(), TRUE, wcscalelist::Wscy1, and wcscalelist::Wyofset1.

01702 {
01703   /*F.Leray 12.10.04 : MODIF named scale_modification*/
01704
01705   sciPointObj *pobj = sciGetCurrentSubWin();
01706   sciSubWindow * ppsubwin = pSUBWIN_FEATURE (pobj);
01707
01708   if(ppsubwin->axes.reverse[1]==TRUE) /* difference is HERE */
01709     return Cscale.frect[1] + (1.0/Cscale.Wscy1)*((y) - Cscale.Wyofset1);
01710   else
01711     return Cscale.frect[3] - (1.0/Cscale.Wscy1)*((y) - Cscale.Wyofset1);
01712
01713
01714
01715   sciprint("Error in Zoom3d_YScale\n");
01716   return -9000;
01717 }

Here is the call graph for this function:

int zoom_box	(	double *	bbox,
		int *	x_pixel,
		int *	y_pixel
	)

Definition at line 1154 of file Plo2dEch.c.

References sciSubWindow::axes, box3d(), C2F, Cscale, FALSE, sciSubWindow::FRect, FreeVertices(), getVertexIndex(), GetVerticesAt(), graduate(), i, InvAxis(), lmax(), lmin(), Max, max, Min, min, NULL, tagSons::pnext, tagSons::pointobj, pSUBWIN_FEATURE, AXES::reverse, SCI_SUBWIN, sciDrawObj(), sciGetCurrentFigure(), sciGetCurrentSubWin(), sciGetEntityType(), sciGetLastSons(), sciGetSons(), sciGetZooming(), sciIsAreaZoom(), sciSetSelectedSubWin(), sciSetZooming(), SetMinMaxVertices(), setVertexIndex(), setZoom3dStatus(), sciSubWindow::SRect, TRUE, wcscalelist::WIRect1, XDouble2Pixel, XPixel2Double, YDouble2Pixel, YPixel2Double, and z.

Referenced by sci_zoom_rect(), and zoom().

01155 {
01156   integer min,max,puiss,deux=2,dix=10,box[4],box1[4],section[4];
01157
01158   double fmin,fmax,lmin,lmax;
01159   sciPointObj *psousfen,*tmpsousfen;
01160   sciPointObj * pfigure = NULL;
01161   sciSons *psonstmp;
01162   sciSubWindow * ppsubwin = NULL; /* debug */
01163
01164   box[0]= Min(XDouble2Pixel(bbox[0]),XDouble2Pixel(bbox[2]));
01165   box[2]= Max(XDouble2Pixel(bbox[0]),XDouble2Pixel(bbox[2]));
01166   box[1]= Min(YDouble2Pixel(bbox[1]),YDouble2Pixel(bbox[3]));
01167   box[3]= Max(YDouble2Pixel(bbox[1]),YDouble2Pixel(bbox[3]));
01168
01169   pfigure = sciGetCurrentFigure();
01170   tmpsousfen= sciGetCurrentSubWin();
01171   psonstmp = sciGetSons (sciGetCurrentFigure());
01172   while (psonstmp != (sciSons *) NULL)
01173   {
01174     if(sciGetEntityType (psonstmp->pointobj) == SCI_SUBWIN)
01175     {
01176       psousfen= (sciPointObj *)psonstmp->pointobj;
01177       if ( pSUBWIN_FEATURE (psousfen)->is3d == TRUE) {
01178         double xmin, ymin;
01179         double xmax, ymax;
01180         double zmin, zmax;
01181         sciSons *psonstmp2 = (sciSons *) NULL;
01182         double epsilon = 1e-16;
01183
01184         int box3d[4];
01185         int section3d[4];
01186
01187         sciSetSelectedSubWin(psousfen);
01188         ppsubwin = pSUBWIN_FEATURE (psousfen);
01189
01190         box3d[0] = x_pixel[0];
01191         box3d[2] = x_pixel[1];
01192         box3d[1] = y_pixel[0];
01193         box3d[3] = y_pixel[1];
01194
01195         box1[0]= Cscale.WIRect1[0];
01196         box1[2]= Cscale.WIRect1[2]+Cscale.WIRect1[0];
01197         box1[1]= Cscale.WIRect1[1];
01198         box1[3]= Cscale.WIRect1[3]+Cscale.WIRect1[1];
01199
01200         if (sciIsAreaZoom(box3d,box1,section3d))
01201         {
01202           int tmp[4],i;
01203
01204           for(i=0;i<4;i++) tmp[i] = section3d[i];
01205
01206           section3d[0] = Min(tmp[0],tmp[2]);
01207           section3d[2] = Max(tmp[0],tmp[2]);
01208           section3d[1] = Min(tmp[1],tmp[3]);
01209           section3d[3] = Max(tmp[1],tmp[3]);
01210
01211           /* determine how many vertices we will have to draw */
01212           /* this is used for 3d zoom (to know size of the global vector) */
01213           setVertexIndex( 0 ) ;
01214
01215           /* this flag is used inside trans3d called many times by sciDrawObj */
01216           setZoom3dStatus( TRUE );
01217
01218           psonstmp2 = sciGetLastSons (psousfen);
01219
01220           sciDrawObj(psousfen); /* see GlobalFlag_Zoom3dOn impact flag in sciDrawObj & trans3d functions */
01221
01222           setZoom3dStatus( FALSE );
01223
01224           SetMinMaxVertices(pSUBWIN_FEATURE(psousfen)->vertices_list, &xmin, &ymin, &zmin, &xmax, &ymax, &zmax);
01225
01226
01227           for( i = 0 ; i < getVertexIndex() ; i++ )
01228           {
01229             int xp,yp;
01230             double x,y,z;
01231
01232             if(GetVerticesAt(pSUBWIN_FEATURE(psousfen)->vertices_list, &xp, &yp, &x, &y, &z)==-1)
01233               break; /* all the vertices have been scanned inside the current psubwin */
01234
01235             if(xp >= section3d[0] && xp <= section3d[2] && yp >= section3d[1] && yp <= section3d[3])
01236             {
01237               /*                          printf("ICI => xp = %d \t yp = %d et x = %lf \t y = %lf \t z = %lf\n",xp,yp,x,y,z); */
01238               if(x < xmin) xmin=x; if(x > xmax) xmax=x;
01239               if(y < ymin) ymin=y; if(y > ymax) ymax=y;
01240               if(z < zmin) zmin=z; if(z > zmax) zmax=z;
01241             }
01242           }
01243
01244           if(ppsubwin->axes.reverse[0] == TRUE) {
01245             double tmp2;
01246             tmp2 = InvAxis(ppsubwin->FRect[0],ppsubwin->FRect[2],xmin);
01247             xmin = InvAxis(ppsubwin->FRect[0],ppsubwin->FRect[2],xmax);
01248             xmax = tmp2;
01249           }
01250
01251           if(ppsubwin->axes.reverse[1] == TRUE) {
01252             double tmp2;
01253             tmp2 = InvAxis(ppsubwin->FRect[1],ppsubwin->FRect[3],ymin);
01254             ymin = InvAxis(ppsubwin->FRect[1],ppsubwin->FRect[3],ymax);
01255             ymax = tmp2;
01256           }
01257
01258           if(ppsubwin->axes.reverse[2] == TRUE) {
01259             double tmp2;
01260             tmp2 = InvAxis(ppsubwin->FRect[4],ppsubwin->FRect[5],zmin);
01261             zmin = InvAxis(ppsubwin->FRect[4],ppsubwin->FRect[5],zmax);
01262             zmax = tmp2;
01263           }
01264
01265           FreeVertices(psousfen);
01266
01267           /* case where no vertex has been selected : */
01268           /* no zoom is performed */
01269           if(xmin > xmax || ymin > ymax || zmin > zmax)
01270           {
01271             xmin = ppsubwin->SRect[0];
01272             xmax = ppsubwin->SRect[1];
01273
01274             ymin = ppsubwin->SRect[2];
01275             ymax = ppsubwin->SRect[3];
01276
01277             zmin = ppsubwin->SRect[4];
01278             zmax = ppsubwin->SRect[5];
01279           }
01280
01281           if (!(sciGetZooming(psousfen)))
01282             sciSetZooming(psousfen, 1);
01283
01284
01285           /* case where a 3d rotated plot2d is zoomed */
01286           if(fabs(zmin) < epsilon && fabs(zmax) < epsilon){
01287             zmin = pSUBWIN_FEATURE (psousfen)->SRect[4];
01288             zmax = pSUBWIN_FEATURE (psousfen)->SRect[5];
01289           }
01290
01291           pSUBWIN_FEATURE (psousfen)->ZRect[0] = xmin;
01292           pSUBWIN_FEATURE (psousfen)->ZRect[2] = xmax;
01293
01294           pSUBWIN_FEATURE (psousfen)->ZRect[1] = ymin;
01295           pSUBWIN_FEATURE (psousfen)->ZRect[3] = ymax;
01296
01297           pSUBWIN_FEATURE (psousfen)->ZRect[4] = zmin;
01298           pSUBWIN_FEATURE (psousfen)->ZRect[5] = zmax;
01299
01300         }
01301       }
01302       sciSetSelectedSubWin(psousfen);
01303       ppsubwin = pSUBWIN_FEATURE (psousfen);
01304
01305       if ( pSUBWIN_FEATURE (psousfen)->is3d == FALSE) {
01306
01307         box1[0]= Cscale.WIRect1[0];
01308         box1[2]= Cscale.WIRect1[2]+Cscale.WIRect1[0];
01309         box1[1]= Cscale.WIRect1[1];
01310         box1[3]= Cscale.WIRect1[3]+Cscale.WIRect1[1];
01311
01312         if (sciIsAreaZoom(box,box1,section))
01313         {
01314           bbox[0]= Min(XPixel2Double(section[0]),XPixel2Double(section[2]));
01315           bbox[2]= Max(XPixel2Double(section[0]),XPixel2Double(section[2]));
01316           bbox[1]= Min(YPixel2Double(section[1]),YPixel2Double(section[3]));
01317           bbox[3]= Max(YPixel2Double(section[1]),YPixel2Double(section[3]));
01318
01319           if (!(sciGetZooming(psousfen)))
01320             sciSetZooming(psousfen, 1);
01321
01323           fmin=  bbox[0];
01324           fmax=  bbox[2];
01325           if(pSUBWIN_FEATURE (psousfen)->logflags[0] == 'n') {
01326             C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01327             pSUBWIN_FEATURE(psousfen)->axes.xlim[2]=puiss;
01328             pSUBWIN_FEATURE (psousfen)->ZRect[0]=lmin;
01329             pSUBWIN_FEATURE (psousfen)->ZRect[2]=lmax;}
01330           else {
01331             pSUBWIN_FEATURE(psousfen)->axes.xlim[2]=0;
01332             pSUBWIN_FEATURE (psousfen)->ZRect[0]=fmin;
01333             pSUBWIN_FEATURE (psousfen)->ZRect[2]=fmax;
01334           }
01335
01336
01337           fmin= bbox[1];
01338           fmax= bbox[3];
01339           if(pSUBWIN_FEATURE (psousfen)->logflags[1] == 'n') {
01340             C2F(graduate)(&fmin, &fmax,&lmin,&lmax,&deux,&dix,&min,&max,&puiss) ;
01341             pSUBWIN_FEATURE(psousfen)->axes.ylim[2]=puiss;
01342             pSUBWIN_FEATURE (psousfen)->ZRect[1]=lmin;
01343             pSUBWIN_FEATURE (psousfen)->ZRect[3]=lmax;}
01344           else {
01345             pSUBWIN_FEATURE(psousfen)->axes.ylim[2]=0;
01346             pSUBWIN_FEATURE (psousfen)->ZRect[1]=fmin;
01347             pSUBWIN_FEATURE (psousfen)->ZRect[3]=fmax;}
01348         }
01349       }
01350     }
01351     psonstmp = psonstmp->pnext;
01352   }
01353   sciSetSelectedSubWin(tmpsousfen);
01354   sciDrawObj(sciGetCurrentFigure());
01355
01356   return 0;
01357 }

Here is the call graph for this function:

Here is the caller graph for this function:

int zoom_get_rectangle	(	double *	bbox,
		int *	x_pixel,
		int *	y_pixel
	)

get a rectangle interactively

XXXXXX : a regler pour Win32 in = 6

XXXX

Definition at line 1057 of file Plo2dEch.c.

References C2F, dr(), dr1(), L, Max, Min, PD0, PI0, ReleaseWinHdc(), SciMouseCapture(), SciMouseRelease(), sciprint(), SetDriver(), SetWinhdc(), style, xclick_2(), xgetmouse2(), and zoom_rect2().

Referenced by zoom().

01058 {
01059   /* Using the mouse to get the new rectangle to fix boundaries */
01060   integer th,th1=1;
01061   integer pixmode,alumode,color,style[10],fg,verbose=0,narg;
01062   integer ibutton,in,iwait=0,istr=0;
01063   integer modes[2];
01064   double x0,yy0,x,y,xl,yl;
01065   int pixel_x, pixel_y;
01066   int pixel_x0, pixel_y0;
01067   /*   int i; */
01068
01069   modes[0]=1;modes[1]=0; /* for xgemouse only get mouse mouvement*/
01070
01071   C2F(dr)("xget","pixmap",&verbose,&pixmode,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01072   C2F(dr)("xget","alufunction",&verbose,&alumode,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01073   C2F(dr)("xget","thickness",&verbose,&th,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01074   C2F(dr)("xget","color",&verbose,&color,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01075   C2F(dr)("xget","line style",&verbose,style,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01076   C2F(dr)("xget","foreground",&verbose,&fg,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01077
01078 #ifdef _MSC_VER
01079   SetWinhdc();
01080   SciMouseCapture();
01081 #endif
01082   C2F(SetDriver)("X11",PI0,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0);
01083   C2F(dr)("xset","thickness",&th1,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01084   C2F(dr)("xset","line style",(in=1,&in),PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01085   C2F(dr)("xset","color",&fg,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01086
01088   C2F(dr1)("xset","alufunction",(in=6,&in),PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01089   /*  C2F(dr1)("xclick","one",&ibutton,&iwait,&istr,PI0,PI0,PI0,&x0,&yy0,PD0,PD0,0L,0L); */
01090   xclick_2("xclick","one",&ibutton,&iwait,&istr,&x_pixel[0],&y_pixel[0],PI0,&x0,&yy0,PD0,PD0,0L,0L);
01091
01092
01093   if(ibutton == -100){
01094     sciprint("Error: window closed while zooming\t\n");
01095     return 1; /* error catch : no need to go further F.Leray 07.09.05 */
01096   }
01097
01098   x=x0;y=yy0;
01099
01100   pixel_x = pixel_x0 = x_pixel[0];
01101   pixel_y = pixel_y0 = y_pixel[0];
01102
01103   ibutton=-1;
01104   while ( ibutton == -1 )
01105     {
01106       /* dessin d'un rectangle */
01107       /* following line commented to solve bug 1314 */
01108       /*       C2F (dr) ("xset", "color",&noir,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0, PD0,0L,0L); */
01109       zoom_rect2(pixel_x0,pixel_y0,pixel_x,pixel_y);
01110       if ( pixmode == 1) C2F(dr1)("xset","wshow",PI0,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01111       xgetmouse2("xgetmouse","one",&ibutton,&iwait,&x_pixel[1],&y_pixel[1],modes,PI0,&xl, &yl,PD0,PD0,0L,0L);
01112
01113       if (ibutton==-100) return 1; /* the window has been closed */  /* error catch : no need to go further F.Leray 07.09.05 */
01114       /* effacement du rectangle */
01115       zoom_rect2(pixel_x0,pixel_y0,pixel_x,pixel_y);
01116       if ( pixmode == 1) C2F(dr1)("xset","wshow",PI0,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01117       x=xl;y=yl;
01118
01119       pixel_x = x_pixel[1];
01120       pixel_y = y_pixel[1];
01121     }
01122 #ifndef _MSC_VER
01123
01124   C2F(dr1)("xset","alufunction",(in=3,&in),PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01125 #endif
01126   /* Back to the default driver which must be Rec and redraw the recorded
01127    * graphics with the new scales
01128    */
01129   /* F.Leray With the new graphic standard, driver has not to be Rec*/
01130
01131
01132   /*   printf("JE SORS et...\n"); */
01133
01134   bbox[0]=Min(x0,x);
01135   bbox[1]=Min(yy0,y);
01136   bbox[2]=Max(x0,x);
01137   bbox[3]=Max(yy0,y);
01138
01139
01140   C2F(dr1)("xset","alufunction",&alumode,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01141   C2F(dr)("xset","thickness",&th,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01142   C2F(dr)("xset","line style",style,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01143   C2F(dr)("xset","color",&color,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01144
01145 #ifdef _MSC_VER
01146   ReleaseWinHdc();
01147   SciMouseRelease();
01148 #endif
01149   return 0;
01150 }

Here is the call graph for this function:

Here is the caller graph for this function:

static void zoom_rect2	(	int	xpix_ini,
		int	ypix_ini,
		int	xpix_fin,
		int	ypix_fin
	)			`[static]`

Win32, warning when using xor mode colors are changed and black is turned to white so we must use an other pattern than the black one inside dbox

Definition at line 1732 of file Plo2dEch.c.

References C2F, dr(), L, PD0, and PI0.

Referenced by zoom_get_rectangle().

01733 {
01734   int closeflag=0;
01735   int cinq=5;
01736
01737   int xm[5], ym[5];
01738
01739   #ifdef _MSC_VER
01740     integer verbose=0,pat,pat1=3,narg;
01741   #endif
01742
01743   if(xpix_ini < xpix_fin){
01744     xm[0] = xpix_ini;
01745     xm[1] = xpix_ini;
01746     xm[4] = xpix_ini;
01747
01748     xm[2] = xpix_fin;
01749     xm[3] = xpix_fin;
01750   }
01751   else{
01752     xm[0] = xpix_fin;
01753     xm[1] = xpix_fin;
01754     xm[4] = xpix_fin;
01755
01756     xm[2] = xpix_ini;
01757     xm[3] = xpix_ini;
01758   }
01759
01760   if(ypix_ini < ypix_fin){
01761     ym[0] = ypix_ini;
01762     ym[3] = ypix_ini;
01763     ym[4] = ypix_ini;
01764
01765     ym[1] = ypix_fin;
01766     ym[2] = ypix_fin;
01767   }
01768   else{
01769     ym[0] = ypix_fin;
01770     ym[3] = ypix_fin;
01771     ym[4] = ypix_fin;
01772
01773     ym[1] = ypix_ini;
01774     ym[2] = ypix_ini;
01775   }
01776
01777 #ifdef _MSC_VER
01778   C2F(dr)("xget","pattern",&verbose,&pat,&narg,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01779   C2F(dr)("xset","pattern",&pat1,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01780 #endif
01781
01782   /*   C2F(dr1)("xrect","v",PI0,PI0,PI0,PI0,PI0,PI0,&xi,&yi,&w,&h,0L,0L); */
01783
01784
01785   C2F (dr) ("xlines", "xv", &cinq, xm, ym, &closeflag, PI0, PI0, PD0, PD0, PD0, PD0,6L,2L);
01786
01787
01788
01789 #ifdef _MSC_VER
01790   C2F(dr)("xset","pattern",&pat,PI0,PI0,PI0,PI0,PI0,PD0,PD0,PD0,PD0,0L,0L);
01791 #endif
01792 }

Here is the call graph for this function:

Here is the caller graph for this function:

WCScaleList Cscale

Initial value:


  {
    0,
    {600,400},
    {0.0,0.0,1.0,1.0},
    {0.0,0.0,1.0,1.0},
    {1/8.0,1/8.0,1/8.0,1/8.0},
    {0.0,1.0,0.0,10},
    {0.0,1.0,0.0,10},
    75.0,53.0,450.0,318.0,
    {'n','n'},
    {75,53,450,318},
    {2,10,2,10},
    {{1.0,0.0,0.0},{0.0,1.0,0.0},{0.0,0.0,1.0}},
    {0.0,1.0,0.0,1.0,0.0,1.0},
    35.0,45.0,
    1,
    (WCScaleList *) 0,
    (WCScaleList *) 0
  }

Definition at line 56 of file Plo2dEch.c.

Referenced by Axes3dStrings2(), axesplot(), axis2d(), axis_draw(), axis_draw2(), box3d(), CheckClickedSubwin(), checkXAxes2dTics(), checkYAxes2dTics(), computeArrowColor(), computeRealArrowSize(), Cscale2default(), DrawAxesBackground(), drawPolylineEntity(), DrawXSubTics(), DrawXTics(), DrawYSubTics(), DrawYTics(), echelle2dl(), ellipse2d(), frame_clip_on(), get_frame_in_pixel(), get_margin_in_pixel(), get_scale_win(), getscale2d(), I3dRotation(), InitAxesModel(), labels2D_draw(), Legends(), Nsetscale2d(), rect2d(), Sci_Axis(), sci_drawaxis(), sci_xchange(), SciAxisNew(), sciChamp2DRealToPixel(), sciUpdateScaleAngles(), set_scale(), SetEch3d1(), ShowScales(), updateScale3d(), XDPi2R(), xechelle2d(), XLogScale(), XPi2R(), XScale(), YDPi2R(), yechelle2d(), YLogScale(), YPi2R(), YScale(), Zoom3d_XPi2R(), Zoom3d_YPi2R(), and zoom_box().

WCScaleList Defscale

Initial value:


  {
    0,
    {600,400},
    {0.0,0.0,1.0,1.0},
    {0.0,0.0,1.0,1.0},
    {1/8.0,1/8.0,1/8.0,1/8.0},
    {0.0,1.0,0.0,10},
    {0.0,1.0,0.0,10},
    75.0,53.0,450.0,318.0,
    {'n','n'},
    {75,53,450,318},
    {2,10,2,10},
    {{1.0,0.0,0.0},{0.0,1.0,0.0},{0.0,0.0,1.0}},
    {0.0,1.0,0.0,1.0,0.0,1.0},
    35.0,45.0,
    1,
    (WCScaleList *) 0,
    (WCScaleList *) 0
  }

default values

Definition at line 79 of file Plo2dEch.c.

Referenced by Cscale2default(), and set_window_scale_with_default().

ScaleList* The_List = NULL [static]

Definition at line 52 of file Plo2dEch.c.

Referenced by addWindowItem(), del_window_scale(), findWindowItem(), get_window_scale(), getFirstWindow(), getLastWindowItem(), getScilabWindowList(), getWindowXgcNumber(), getWins(), getWinsMaxId(), isWindowListEmpty(), removeWindowItem(), set_window_scale(), and ShowScales().


Functions
void	xgetmouse2 (char fname, char str, integer ibutton, integer iflag, integer x1, integer yy1, integer x6, integer x7, double x, double y, double dx3, double dx4, integer lx0, integer lx1)
void	xclick_2 (char fname, char str, integer ibutton, integer iflag, integer istr, integer x1, integer yy1, integer x7, double x, double y, double dx3, double dx4, integer lx0, integer lx1)
int	StoreCommand (char *command)
static void scale_copy	__PARAMS ((WCScaleList s1, WCScaleList s2))
static integer curwin	__PARAMS ((void))
static void	zoom_rect2 (int xpix_ini, int ypix_ini, int xpix_fin, int ypix_fin)
static void set_scale_win	__PARAMS ((ScaleList *listptr, integer i, WCScaleList s))
static WCScaleList *new_wcscale	__PARAMS ((WCScaleList *val))
static WCScaleList *check_subwin_wcscale	__PARAMS ((WCScaleList listptr, double ))
static int same_subwin	__PARAMS ((double lsubwin_rect[4], double subwin_rect[4]))
static void set_window_scale	__PARAMS ((integer i, WCScaleList *scale))
void	Cscale2default (void)
void	set_window_scale_with_default (int i)
static int get_scale_win	__PARAMS ((ScaleList listptr, integer wi, double subwin))
int	get_window_scale (integer i, double *subwin)
static int	get_scale_win (ScaleList listptr, integer wi, double subwin)
static void	set_window_scale (integer i, WCScaleList *scale)
static void	set_scale_win (ScaleList *listptr, integer i, WCScaleList scale)
static WCScaleList *	new_wcscale (WCScaleList *val)
static WCScaleList *	check_subwin_wcscale (WCScaleList *listptr, subwin_rect)
static int	same_subwin (lsubwin_rect, subwin_rect)
static void DeleteWCScale	__PARAMS ((WCScaleList *l))
void	del_window_scale (integer i)
static void	DeleteWCScale (WCScaleList *l)
static void	scale_copy (WCScaleList s1, WCScaleList s2)
static integer	curwin (void)
static void show_scales	__PARAMS ((ScaleList *listptr))
void	ShowScales (void)
static void	show_scales (ScaleList *listptr)
int C2F()	setscale2d (WRect, FRect, char *logscale, integer l1)
int C2F()	Nsetscale2d (double WRect[4], double ARect[4], double FRect[4], char *logscale, integer l1)
int	getscale2d (double WRect[4], double FRect[4], char *logscale, double ARect[4])
void	get_frame_in_pixel (integer WIRect[])
void	get_margin_in_pixel (integer Margin[])
void	set_scale (char flag[6], double subwin[4], double frame_values[4], integer aaint[4], char logflag[3], double axis_values[4])
void	get_cwindow_dims (int wdims[2])
int C2F()	xechelle2d (x, x1,*n1, dir, integer lstr)
int C2F()	yechelle2d (y, yy1,*n2, dir, integer lstr)
int C2F()	echelle2d (double x[], double y[], integer x1[], integer yy1[], integer n1, integer n2, char dir[], integer lstr)
void C2F()	echelle2dl (double x[], double y[], integer x1[], integer yy1[], integer n1, integer n2, char *dir)
void C2F()	ellipse2d (double x[], integer x1[], integer n, char dir)
void C2F()	rect2d (double x[], integer x1[], integer n, char dir)
void C2F()	axis2d (double alpha, double initpoint, double size, integer initpoint1, double *size1)
int	EchCheckSCPlots ()
int	zoom_get_rectangle (double bbox, int x_pixel, int *y_pixel)
int	zoom_box (double bbox, int x_pixel, int *y_pixel)
int	zoom ()
void	unzoom ()
void	unzoom_one_axes (sciPointObj *psousfen)
void	Gr_Rescale (char logFlags, double FRectI, integer Xdec, integer Ydec, integer xnax, integer ynax)
int	XScale (double x)
int	XLogScale (double x)
int	YScale (double y)
int	YLogScale (double y)
double	XPi2R (int x)
double	YPi2R (int y)
double	XDPi2R (double x)
double	YDPi2R (double y)
double	Zoom3d_XPi2R (int x)
double	Zoom3d_YPi2R (int y)
void	scizoom (double bbox[4], sciPointObj *pobj)
void	getPixelCoordinates (sciPointObj *pSubWin, double coord3d[3], int pixCoord[2])
int	PixelHeight2d (sciPointObj *parentSubWin, double posY, double height)
int	PixelWidth2d (sciPointObj *parentSubWin, double posX, double width)
void	rectangleDouble2Pixel (sciPointObj *parentSubWin, double ulPoint[3], double userSize[2], int edgesX[4], int edgesY[4])
void	Plo2d2RealToPixel (integer n1, integer n2, double x, double y, integer xm, integer ym, char *xf)
void	Plo2d3RealToPixel (integer n1, integer n2, double x, double y, integer xm, integer ym, char *xf)
void	Plo2d4RealToPixel (integer n1, integer n2, double x, double y, integer xm, integer ym, char *xf)
Variables
static ScaleList *	The_List = NULL
WCScaleList	Cscale
WCScaleList	Defscale

Plo2dEch.c File Reference

Functions

Variables

Function Documentation

Variable Documentation
