Overview

R-CMD-check Codecov test coverage CRAN status CRAN downloads CRAN downloads DOI

Capture-recapture type experiments are used to estimate the total population size in situations when observing only a part of such population is feasible. In recent years these types of experiments have seen more interest.

Single source models are distinct from other capture-recapture models because we cannot estimate the population size based on how many units were observed in two or three sources which is the standard approach.

Instead in single source models we utilize count data regression models on positive distributions (i.e. on counts greater than 0) where the dependent variable is the number of times a particular unit was observed in source data.

This package aims to implement already existing and introduce new methods of estimating population size from single source to simplify the research process.

Currently we’ve implemented most of the frequentist approaches used in literature such as:

Installation

You can install the current version of singleRcapture from main branch GitHub with:

# install.packages("devtools")
remotes::install_github("ncn-foreigners/singleRcapture")

or install the stable version from CRAN with:

install.packages(singleRcapture)

or development version from development branch on GitHub with:

# install.packages("devtools")
remotes::install_github("github.com/ncn-foreigners/singleRcapture/tree/development")

Examples

The main function of this package is estimatePopsize which fitts regression on specified distribution and then uses fitted regression to estimate the population size.

Lets look at a model from 2003 publication : Point and interval estimation of the population size using the truncated Poisson regression model Heijden, Peter GM van der et al. The call to estimatePopsize will look very similar to anyone who used the stats::glm function:

library(singleRcapture)
model <- estimatePopsize(
  formula = capture ~ gender + age + nation, # specify formula
  data = netherlandsimmigrant,
  popVar = "analytic", # specify
  model = "ztpoisson", # distribution used
  method = "IRLS", # fitting method one of three currently supported
  controlMethod = controlMethod(silent = TRUE) # ignore convergence at half step warning
)
summary(model) # a summary method for singleR class with standard glm-like output and population size estimation resutls
#>
#> Call:
#> estimatePopsize.default(formula = capture ~ gender + age + nation,
#>     data = netherlandsimmigrant, model = "ztpoisson", method = "IRLS",
#>     popVar = "analytic", controlMethod = controlMethod(silent = TRUE))
#>
#> Pearson Residuals:
#>      Min.   1st Qu.    Median      Mean   3rd Qu.      Max.
#> -0.486442 -0.486442 -0.298080  0.002093 -0.209444 13.910844
#>
#> Coefficients:
#> -----------------------
#> For linear predictors associated with: lambda
#>                      Estimate Std. Error z value  P(>|z|)
#> (Intercept)           -1.3411     0.2149  -6.241 4.35e-10 ***
#> gendermale             0.3972     0.1630   2.436 0.014832 *
#> age>40yrs             -0.9746     0.4082  -2.387 0.016972 *
#> nationAsia            -1.0926     0.3016  -3.622 0.000292 ***
#> nationNorth Africa     0.1900     0.1940   0.979 0.327398
#> nationRest of Africa  -0.9106     0.3008  -3.027 0.002468 **
#> nationSurinam         -2.3364     1.0136  -2.305 0.021159 *
#> nationTurkey          -1.6754     0.6028  -2.779 0.005445 **
#> ---
#> Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> AIC: 1712.901
#> BIC: 1757.213
#> Residual deviance: 1128.553
#>
#> Log-likelihood: -848.4504 on 1872 Degrees of freedom
#> Number of iterations: 8
#> -----------------------
#> Population size estimation results:
#> Point estimate 12690.35
#> Observed proportion: 14.8% (N obs = 1880)
#> Std. Error 2808.169
#> 95% CI for the population size:
#>           lowerBound upperBound
#> normal      7186.444   18194.26
#> logNormal   8431.275   19718.32
#> 95% CI for the share of observed population:
#>           lowerBound upperBound
#> normal     10.332927   26.16037
#> logNormal   9.534281   22.29793

We implemented a method for plot function to visualise the model fit and other useful diagnostic information. One of which is rootogram, a type of plot that compares fitted and observed marginal frequencies:

plot(model, plotType = "rootogram")

The possible values for plotType argument are:

a user can also pass arguments to specify additional information such as plot title, subtitle etc. similar to calling plot on some data. For more info check plot.singleR method documentation.

As we have seen there are some significant differences between fitted and observed marginal frequencies. To check our intuition let’s perform goodness of fit test between fitted and observed marginal frequencies.

To do it we call a summary function of marginalFreq function which computes marginal frequencies for the fitted singleR class object:

summary(marginalFreq(model), df = 2, dropl5 = "group")
#> Test for Goodness of fit of a regression model:
#>
#>                  Test statistics df P(>X^2)
#> Chi-squared test           50.06  2 1.3e-11
#> G-test                     34.31  2 3.6e-08
#>
#> --------------------------------------------------------------
#> Cells with fitted frequencies of < 5 have been grouped
#> Names of cells used in calculating test(s) statistic: 1 2 3

Finally let us check if we have any influential observations. We will do this by comparing the deletion effect of every observation on population size estimate by removing it entirely from the model (from population size estimate and regression) and by only omitting it in pop size estimation (this is what is called the contribution of an observation). If observation is not influential these two actions should have the approximately the same effect:

plot(model, plotType = "dfpopContr")

it is easy to deduce from the plot above that we have influential observations in our dataset (one in particular).

Lastly singleRcapture offers some posthoc procedures for example a function stratifyPopsize that estimates sizes of user specified sub populations and returns them in a data.frame:

stratifyPopsize(model, alpha = c(.01, .02, .03, .05), # different significance level for each sub population
    stratas = list(
    "Females from Surinam" = netherlandsimmigrant$gender == "female" & netherlandsimmigrant$nation == "Surinam",
    "Males from Turkey" = netherlandsimmigrant$gender == "male" & netherlandsimmigrant$nation == "Turkey",
    "Younger males" = netherlandsimmigrant$gender == "male" & netherlandsimmigrant$age == "<40yrs",
    "Older males" = netherlandsimmigrant$gender == "male" & netherlandsimmigrant$age == ">40yrs"
))
#>   Observed Estimated ObservedPercentage  StdError normalLowerBound
#> 1       20   931.469           2.147146  955.0676      -1528.62209
#> 2       78  1291.251           6.040652  741.0066       -432.58790
#> 3     1391  7337.072          18.958516 1282.1419       4554.70841
#> 4       91  1542.189           5.900703  781.4754         10.52561
#>   normalUpperBound logNormalLowerBound logNormalUpperBound                 name
#> 1         3391.560            119.2661            8389.178 Females from Surinam
#> 2         3015.090            405.4127            4573.791    Males from Turkey
#> 3        10119.436           5134.8113           10834.792        Younger males
#> 4         3073.853            630.7551            3992.677          Older males
#>   confLevel
#> 1      0.01
#> 2      0.02
#> 3      0.03
#> 4      0.05

stratas argument may be specified in various ways for example:

stratifyPopsize(model, stratas = ~ gender / age)
#>   Observed Estimated ObservedPercentage  StdError normalLowerBound
#> 1      398 3811.0924          10.443200 1153.9749       1549.34322
#> 2     1482 8879.2613          16.690578 1812.0813       5327.64720
#> 3      378 3169.8272          11.924940  880.9491       1443.19883
#> 4     1391 7337.0721          18.958516 1282.1419       4824.12025
#> 5       20  641.2651           3.118835  407.5268       -157.47265
#> 6       91 1542.1892           5.900703  781.4754         10.52561
#>   normalUpperBound logNormalLowerBound logNormalUpperBound
#> 1         6072.842           2189.0439            6902.140
#> 2        12430.875           6090.7752           13354.889
#> 3         4896.456           1904.3121            5484.622
#> 4         9850.024           5306.3298           10421.088
#> 5         1440.003            212.3382            2026.728
#> 6         3073.853            630.7551            3992.677
#>                     name confLevel
#> 1         gender==female      0.05
#> 2           gender==male      0.05
#> 3 genderfemale:age<40yrs      0.05
#> 4   gendermale:age<40yrs      0.05
#> 5 genderfemale:age>40yrs      0.05
#> 6   gendermale:age>40yrs      0.05

The package was designed with convenience in mind, for example it is possible to specify that weights provided on call are to be interpreted as number of occurrences of units in each row:

df <- netherlandsimmigrant[, c(1:3,5)]
df$ww <- 0
### this is dplyr::count without dependencies
df <- aggregate(ww ~ ., df, FUN = length)
summary(estimatePopsize(
  formula = capture ~ nation + age + gender,
  data = df,
  model = ztpoisson,
  weights = df$ww,
  controlModel = controlModel(weightsAsCounts = TRUE)
))
#>
#> Call:
#> estimatePopsize.default(formula = capture ~ nation + age + gender,
#>     data = df, model = ztpoisson, weights = df$ww, controlModel = controlModel(weightsAsCounts = TRUE))
#>
#> Pearson Residuals:
#>      Min.   1st Qu.    Median      Mean   3rd Qu.      Max.
#> -317.6467   -2.4060    3.7702    0.0803   13.4920  183.2108
#>
#> Coefficients:
#> -----------------------
#> For linear predictors associated with: lambda
#>                      Estimate Std. Error z value  P(>|z|)
#> (Intercept)           -1.3411     0.2149  -6.241 4.35e-10 ***
#> nationAsia            -1.0926     0.3016  -3.622 0.000292 ***
#> nationNorth Africa     0.1900     0.1940   0.979 0.327398
#> nationRest of Africa  -0.9106     0.3008  -3.027 0.002468 **
#> nationSurinam         -2.3364     1.0136  -2.305 0.021159 *
#> nationTurkey          -1.6754     0.6028  -2.779 0.005445 **
#> age>40yrs             -0.9746     0.4082  -2.387 0.016972 *
#> gendermale             0.3972     0.1630   2.436 0.014832 *
#> ---
#> Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> AIC: 1712.901
#> BIC: 1757.213
#> Residual deviance: 1128.553
#>
#> Log-likelihood: -848.4504 on 1872 Degrees of freedom
#> Number of iterations: 8
#> -----------------------
#> Population size estimation results:
#> Point estimate 12690.35
#> Observed proportion: 14.8% (N obs = 1880)
#> Std. Error 2808.169
#> 95% CI for the population size:
#>           lowerBound upperBound
#> normal      7186.444   18194.26
#> logNormal   8431.275   19718.32
#> 95% CI for the share of observed population:
#>           lowerBound upperBound
#> normal     10.332927   26.16037
#> logNormal   9.534281   22.29793

Methods such as regression diagnostics will be adjusted (values of weights will be reduced instead of rows being removed etc.)

We also included option to use common non standardargument such as significance levels different from usual 5%:

set.seed(123)
modelInflated <- estimatePopsize(
    formula = capture ~ gender + age,
    data = netherlandsimmigrant,
    model = "oiztgeom",
    method = "IRLS",
    # control parameters for population size estimation check documentation of controlPopVar
    controlPopVar = controlPopVar(
        alpha = .01, # significance level
    )
)
summary(modelInflated)
#>
#> Call:
#> estimatePopsize.default(formula = capture ~ gender + age, data = netherlandsimmigrant,
#>     model = "oiztgeom", method = "IRLS", controlPopVar = controlPopVar(alpha = 0.01,
#>         ))
#>
#> Pearson Residuals:
#>      Min.   1st Qu.    Median      Mean   3rd Qu.      Max.
#> -0.357193 -0.357193 -0.357193  0.000343 -0.287637 10.233608
#>
#> Coefficients:
#> -----------------------
#> For linear predictors associated with: lambda
#>             Estimate Std. Error z value P(>|z|)
#> (Intercept)  -1.5346     0.1846  -8.312 < 2e-16 ***
#> gendermale    0.3863     0.1380   2.800 0.00512 **
#> age>40yrs    -0.7788     0.2942  -2.648 0.00810 **
#> -----------------------
#> For linear predictors associated with: omega
#>             Estimate Std. Error z value  P(>|z|)
#> (Intercept)  -1.7591     0.3765  -4.673 2.97e-06 ***
#> ---
#> Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> AIC: 1736.854
#> BIC: 1759.01
#> Residual deviance: 1011.271
#>
#> Log-likelihood: -864.4272 on 3756 Degrees of freedom
#> Number of iterations: 6
#> -----------------------
#> Population size estimation results:
#> Point estimate 5661.522
#> Observed proportion: 33.2% (N obs = 1880)
#> Std. Error 963.9024
#> 99% CI for the population size:
#>           lowerBound upperBound
#> normal      3178.674   8144.370
#> logNormal   3861.508   9096.681
#> 99% CI for the share of observed population:
#>           lowerBound upperBound
#> normal      23.08343   59.14416
#> logNormal   20.66688   48.68564

and the option to estimate standard error of population size estimate by bootstrap, models with more than one distribution parameter being dependent on covariates and some non standard link functions for example:

modelInflated2 <- estimatePopsize(
    formula = capture ~ age,
    data = netherlandsimmigrant,
    popVar = "bootstrap",
    model = oiztgeom(omegaLink = "cloglog"),
    method = "IRLS",
    controlPopVar = controlPopVar(
        B = 500,# number of boostrap samples
        alpha = .01, # significance level
        # type of bootstrap see documentation for estimatePopsize
        bootType = "semiparametric",
        # control regression fitting on bootstrap samples
        bootstrapFitcontrol = controlMethod(
          epsilon = .Machine$double.eps,
          silent = TRUE,
          stepsize = 2
        )
    ),
    controlModel = controlModel(omegaFormula = ~ gender) # put covariates on omega i.e. the inflation parameter
)
#> Warning in singleRcaptureinternalIRLSmultipar(dependent = y, covariates = X, :
#> Convergence at halfstepsize
#> Warning in estimatePopsize.default(formula = capture ~ age, data = netherlandsimmigrant, : The (analytically computed) hessian of the score function is not negative define.
#> NOTE: Second derivative test failing does not
#>         necessarily mean that the maximum of score function that was found
#>         numericaly is invalid since R^k is not a bounded space.
#> Additionally in one inflated and hurdle models second derivative test often fails even on valid arguments.
#> Warning in estimatePopsize.default(formula = capture ~ age, data =
#> netherlandsimmigrant, : Switching from observed information matrix to Fisher
#> information matrix because hessian of log-likelihood is not negative define.
popSizeEst(modelInflated2)
#> Point estimate: 5496.374
#> Variance: 1217985
#> 99% confidence intervals:
#> lowerBound upperBound
#>   4002.763  10231.717

the results are significantly different (the warning issued concerns the second derivative test for existence of local minimum, here it was inconclusive but we manually checked that fitting process found the optimal regression coefficients it’s here to provide more information to the user):

plot(modelInflated2,
     plotType = "bootHist",
     labels = TRUE,
     ylim = c(0, 175),
     breaks = 15)

and information criteria support the second model:

#>  First model: AIC = 1736.854 BIC = 1759.01
#> Second model: AIC = 1734.803 BIC = 1756.959

Funding

Work on this package is supported by the the National Science Center, OPUS 20 grant no. 2020/39/B/HS4/00941.
