exdqlm — Extended Dynamic Quantile Linear Models

exdqlm fits dynamic quantile state-space models using the extended Asymmetric Laplace (exAL) error family. It targets time-series applications where the goal is to model conditional quantiles (not only means) while keeping a familiar state-space specification (design/evolution matrices and a state vector). In v0.3.0, we add optional C++ bridges for speed (Kalman filter and samplers) and ELBO monitoring for the variational routine. Defaults remain pure-R for easy installation.

Terminology. We say exAL for the extended Asymmetric Laplace family used here. It extends the standard AL by adding a skewness parameter; AL is the special case with zero skewness.

Installation

CRAN (when available):

install.packages("exdqlm")

Development (GitHub):

# install.packages("pak")
pak::pak("AntonioAPDL/exdqlm")

Quick start (≤ 10 lines)

Local-level model at a single quantile (the median). We fix scale and skewness to keep it fast and stable for CRAN; we keep the pure-R path.

set.seed(1)
library(exdqlm)

T      <- 120
state  <- cumsum(rnorm(T, sd = 0.2))
y      <- state + rnorm(T, sd = 1.0)

model  <- list(FF = matrix(1), GG = matrix(1), m0 = 0, C0 = 100)
options(exdqlm.use_cpp_kf = FALSE, exdqlm.use_cpp_samplers = FALSE)

fit <- exdqlmISVB(
  y = y, p0 = 0.5, model = model, df = 0.98, dim.df = 1,
  fix.sigma = TRUE, sig.init = 1.0,
  fix.gamma = TRUE, gam.init = 0.0
)
#> ISVB converged: 2 iterations, 0.514 seconds

tail(fit$diagnostics$elbo, 3)
#> [1] -113.62048  -67.45699

Core concepts (at a glance)

State-space skeleton: design (FF) and evolution (GG) matrices with a prior for the state vector (m0, C0).
Quantile of interest: p0 (e.g., 0.1, 0.5, 0.9).
exAL errors: controlled by scale and skewness; fixing them often stabilizes small examples.
Discount factors: df and dim.df control evolution per block (e.g., trend vs seasonality).
ELBO: recorded at fit$diagnostics$elbo (weakly monotone up to importance-sampling noise).

What’s new in v0.3.0

C++ Kalman filter bridge (drop-in): set options(exdqlm.use_cpp_kf = TRUE) (default FALSE; examples keep it OFF).
ELBO monitoring for IS-VB: per-iteration values in fit$diagnostics$elbo.
Optional C++ samplers for posterior draws: set options(exdqlm.use_cpp_samplers = TRUE) (default FALSE).
Portability: OpenMP is optional and gated; package runs serially when unavailable.

Keep both options FALSE in examples/CI. Enable them locally if your toolchain supports compiled code.

Runtime options (summary)

Option	Default	Effect	Use when…
`exdqlm.use_cpp_kf`	FALSE	C++ Kalman filter bridge	you have compilers/OpenMP and want speed
`exdqlm.use_cpp_samplers`	FALSE	C++ samplers for posterior draws	same as above; keep OFF on CRAN/examples

Set with:

options(exdqlm.use_cpp_kf = TRUE)
options(exdqlm.use_cpp_samplers = TRUE)

Minimal examples (CRAN-safe)

1) Single-quantile fit on built-in data (tiny slice)

Trend + seasonality + one regressor (nino34). Note: FF for the regressor is 1 × T. Combine components pairwise.

set.seed(2)
T <- 150
y <- log(BTflow[seq_len(T)])
x <- nino34[seq_len(T)]

trend.comp <- polytrendMod(order = 1, m0 = 0, C0 = 1)
seas.comp  <- seasMod(p = 12, h = 1, C0 = diag(1, 2))

# 1-d regressor block (explicit 1 x T design)
reg.comp <- list(m0 = 0, C0 = 1, FF = matrix(x, nrow = 1), GG = matrix(1))

# combine pairwise
base.mod <- combineMods(trend.comp, seas.comp)
model    <- combineMods(base.mod, reg.comp)

# one discount per block: (trend, seasonal[2-d], reg)
df     <- c(1.00, 0.98, 1.00)
dim.df <- c(1,       2,   1)

options(exdqlm.use_cpp_kf = FALSE, exdqlm.use_cpp_samplers = FALSE)

fit <- exdqlmISVB(
  y = y, p0 = 0.5, model = model,
  df = df, dim.df = dim.df,
  fix.sigma = TRUE, sig.init = 0.2,
  fix.gamma = TRUE, gam.init = 0.0
)
#> ISVB converged: 2 iterations, 0.547 seconds

# quick checks
tail(fit$diagnostics$elbo, 2)
#> [1] -1078.8072  -934.9032
dim(fit$theta.out$sm)  # state-dimension x time
#> [1]   4 150

2) exAL helper sanity check (CDF ↔︎ quantile)

set.seed(3)
x      <- seq(-2, 2, length.out = 5)
p0     <- 0.25
mu     <- 0
sigma  <- 1
gamma  <- 0.0

# CDF then invert with QF — should approximately return x
cdf_vals <- pexal(x,  p0 = p0, mu = mu, sigma = sigma, gamma = gamma)
x_back   <- qexal(cdf_vals, p0 = p0, mu = mu, sigma = sigma, gamma = gamma)

round(cbind(x, x_back), 4)
#>       x x_back
#> [1,] -2     -2
#> [2,] -1     -1
#> [3,]  0      0
#> [4,]  1      1
#> [5,]  2      2

# A few random draws
rexal(5, p0 = p0, mu = mu, sigma = sigma, gamma = gamma)
#> [1] -0.5296664  5.4402490  0.7934288  0.4376783  2.5354967

CRAN-safety. All examples set a seed, use tiny data, finish in a few seconds, and keep the pure-R path by default.

FAQ / Troubleshooting

It runs slowly. Use short series (≤ 200), fix scale/skewness, and keep discount factors near but below one (≈ 0.96–0.99). Enable C++ bridges only if your toolchain supports them.
ELBO dips slightly—bug? Small downward blips are expected from importance-sampling noise. Look for an overall upward trend; if not, simplify the model or adjust variance/discounts.
OpenMP not available. That’s fine. It is optional. Everything runs serially; examples here use the pure-R path.
Numerical stability tips. Avoid extremely tight C0; start with moderate priors (e.g., C0 around 1–100 for simple models), and fix scale/skewness for initial runs.

How to cite

Barata, R., Prado, R., & Sansó, B. (2022). Fast inference for time-varying quantiles via flexible dynamic models with application to the characterization of atmospheric rivers. Annals of Applied Statistics, 16(1), 247–271. https://doi.org/10.1214/21-AOAS1497

License

Getting help

Open an issue: https://github.com/AntonioAPDL/exdqlm/issues
